2015 China Manufacture Powder Dryer Machine with High Efficience
Application of 2015 China Manufacture Powder Dryer Machine with High Efficience
Rotary dryer is used for drying materials with humidity or granularity in the industries Of mineral dressing building material,metallurgy and chemical,It can be used for drying Many kinds of materials such as:limestone slag,coal powder,stag,and clay stone,and It is made from rotary body,lifting blade,driving device,supporting device and sealing Ring.
Characteristics of 2015 China Manufacture Powder Dryer Machine with High Efficience
The dryer has advantages of reasonable structure high efficiency low energy consumption,convenient for transportation,and reliable operation;Therefore the consumption of the coal and the electricity is lower than the common ones,while the Production capacity is 10-15% higher.the operation is very simple and reliabele. For this reason and it is used widly.
Working principle 2014 China Manufacture Powder Dryer Machine with High Efficience
1.bucket elevator;it is used for transporting dried material into the feeder.
2.feeder;it is used to send the material into the rotary drier silo.
3.feeder cover: it can keep materials not leaking and maintain the temperature of pulp.
4.drum dryer: the dryer rotates slowly by motor power to heat material evenly.
5.lifting plate:through the rotating of transfer cylinder and the mixing of the lifting plate, the materials are heated fully and the water is evaporated.
6.dust blower.
7.dust collector cyclone;the dust generated by the mixing of the dried material in the warehouse was discharged out through dust fan and dust collector cyclone, this drying way is environmental.
8.discharging cover,maintain the temperature in the silo, discharge the dry materials orderly.
9.Rotary discharging feeder: The dry materials are transported on the belt conveyor through rotary discharging feeder.
10.belt conveyor;the dried materials are transported into product stock by the belt conveyor or directly bulked.
main technical parameters |
|||||||||
|
Model (m) |
Capacity (T/H) |
power of main frame |
Reducer |
Weight (T) |
|||||
power(KW) |
Model |
Model |
speed ratio |
||||||
HG0.6*8m |
1-1.5 |
4 |
|
|
|
2.5 |
|||
HG0.8*10m |
1.5-2 |
7.5 |
|
|
|
12.2 |
|||
HG1.2×10m |
2.5 |
7.5 |
Y160M-R3 |
ZL50-16-I |
|
13.5 |
|||
HG1.5×12m |
3.3-4.9 |
10 |
Y160L-6-B3 |
JZQ500-Ⅲ-2F |
|
18.9 |
|||
HG1.5×15m |
4-6 |
11 |
Y200L1-6 |
JZQ500-Ⅲ-2F |
|
21 |
|||
HG1.8×12m |
4-6 |
18.5 |
Y160L-6 |
ZQ50-16Ⅱ-2 |
16.46 |
22.83 |
|||
HG2.2×12m |
7-12 |
18.5 |
Y200L7-6 |
JZQ650-Ⅲ |
31.5 |
37.6 |
|||
HG2.2×14m |
7-12 |
18.5 |
Y200L7-6 |
JZQ650-Ⅲ |
31.5 |
40 |
|||
HG2.2×16m |
12 |
30 |
Y225M-6 |
JZQ750-Ⅲ |
31.5 |
45 |
|||
HG2.4×14m |
12 |
30 |
Y250M-6 |
JZQ750-Ⅲ |
31.5 |
51 |
|||
HG2.4×18m |
10-13 |
37 |
Y250M-6 |
ZL85-13-I |
27.16 |
54 |
|||
HG2.4×20m |
10-14 |
37 |
Y250N-6 |
ZL85-13-I |
27.16 |
54.14 |
|||
HG3×20m |
25 |
55 |
Y250M-4 |
ZL100-16-I |
41.52 |
78 |
|||
HG3×25m |
32-36 |
75 |
YR280M-4 |
ZL100-16-I |
41.52 |
104.9 |
|||
Notes during using:
1.Please read operation manual carefully before use.the machine may only be operated by fully authorized,trained personnel.
2.Make sure that the machine starts without any load. The machine can only be started after.All people are away from it.and wear safety helmet and pay attention to flying stones,please stand outside the safe distance.
3.when machine running All adjustment,clearance or check-up is strictly prohibited keep away from any running part. Overloaded operation is strictly prohibited.
4.Lubricator and maintain the machine timely before halt for check,feeder should be first stopped feeding and make sure the stones are all out of the machine silo.
Our certificates
Cooperation with foreign customers
If you're interested in the product, please submit your requirements and contacts and then we will contact you in two days. We promise that all your information won't be leaked to anyone.
