Mini Motorized Rotation Stage( diameter 200mm with 90mm through hole )
Specification
Item Number |
01DX200 |
Angle Range |
360° |
Dimension |
diameter 200mm |
Worm Gear Ratio |
180:1 |
Drive Mechanism |
Worm Gear |
Guide |
Bearing |
Stepper Motor(1.8°) |
SST57D3301 |
Material |
Aluminum |
Surface Treatment |
Black- Anodized |
Loading |
55kg |
Weight |
7.9kg |
Resolution |
0.01°non-driver 0.005°20 MS driver |
Speed |
20°/sec |
Repeatability |
0.005° |
Accuracy |
0.01° |
Run Out of Top |
15μm |
Backlash |
0.005° |
Eccentricity |
5μm |
Degree of Parallelization |
80μm |
Feature
*Regular stage set with stepper motor and RS232 interface, could connect with mo tion controller easily
*High precision Worm gear design for high accuracy, loading and long working time
*Forward and reverse rotate are possible
*The stage could use in vertical and assemble with other stages
*200mm diameter dimension and with dia 90mm through hole for add rotating encode possible
*The regular stage without limit switch and home position, but can add according to requirements
Product drawings
