infant incubator BB-200 standard Dison brand

Baby Incubator

BB-200 Standard

1. Microprocessor based servo controlled temperature system

2. Air temperature, skin temperature, timer and heating power separately displayed by LED

3.Skin temperature sensor failure protect function avoid over temperature

4. Integral timer to record therapy time

5.Alarm functions: Power failure; Over temperature; Temperature deviation; Temperature sensor failure; Fan failure;

6. Temperature deviation and over temperature could be amended in front panel directly

7. Slience/reset button for alarms

8. >37 ℃ temperature setting

9. A keypad lock prevent inadvertent changes the setting

10. A second thermal cut-off function for more safety

11. Humidity is adjustable continuously

12. The infant bed inclination angle is adjustable continuously

13. Trough for pulling and pushing, which is convenient to add water and wash

14. Fan with low noise and long life-span

15. Six operating windows, two sides access operating windows can be swiveled

16. Four drawers for easy storage

17. Heater is electrically cut-out if air temperature inside incubator exceed 40 ℃

18.RS232 Connector

19.Monitor Tray

20. Control part can be pull out in whole,convenient for clean and maintain

21.Oxygen inlet

1. Power supply: AC110/220V 60/50Hz

2. Power input: ≤ 650VA

3 Optional parts:

a. Environment temperature: 20~30℃

b. Environment relative humidity: 30%~75%RH

c. Environment air velocity of flow: <0.3m/s

d.Ambient air pressure: 700 hPa -1060 hPa

4.Air Temperature control range: 25℃-37℃, 37.1℃-38℃

5. Skin temperature control range: 32℃～37℃, 37.1℃～38℃

6. Skin temperature sensor accuracy: +/-0.3℃

7. Temperature fluctuation: +/-0.5℃

8. Uniformity of mattress temperature: ≤ 0.8℃

9. Humidity accuracy: ≤ 10%RH

10. Warm-up time: ≤ 45min

11. Internal noise level: ≤ 55dB

12. Infant bed tilt angle: +/-12 degree

13. Mattress size: 65cm(L)X 37cm(W)

14. Trough capacity: 1200ml

15. Air filter: 0.5um

16.Max CO2-concentration is 0.4%

17.Alarm:

a.The over temp of air temp : 38℃

b.The second thermal cut-out temperature: 40℃

c.The alarm for deviation: - Air temp: ±3.0℃ - Skin temp : ±1.0℃

d.Alarm for Sensors:

When the skin (or air) temperature sensor is shut off or short circuit，cut off the heater，give out alarm with sound and light .

e.Alarm for power failure

The power fails，give out alarm with sound and light.

f.Alarm for fan failure

The fan stops working or has fault, give out alarm with sound and light and cut off the heater power.
