Speaker adopt coaxial speaker and use of original technology with magnetic double-loop.
Characteristics:
1.Speaker adopt coaxial speaker and use of original technology with magnetic double-loop. Speaker of high pitch and bass sound film pronouncing in the same axis, realized the high pitch and bass sounds simultaneously, no time difference, Clear voice, high fidelity, high frequency positioning accurate, sound field distribution. Both horizontal and vertical spread angle are120 °
2.The external form of speaker is a simple and neat appearance, novel model, small size.12 "is equivalent to normal 10" speaker size, light weight and big power.
3.Speaker performance is stable, reliable and durable. Speaker of the divider line has designed treble whistle protection device and the use of Speaker protection is Stable and reliable.
4.Convenient hanging, the speaker hanging device designed to meet a variety of ways to hoisting, very convenient to fixed in the walls and ceiling, and can comprehensive adjust speaker angle .
5.Speaker power components adopt PFC technology switching power, suitable for the whole supply voltage range AC 90-264V 45Hz-65Hz global power.
6.TK series active speaker amplifier parts adopt class D digital power amplifier circuits, energy conversion efficiency, low-carbon environment.
7.Plug and play, user-friendly, clear indication, easy manipulating for nonprofessionals.
8.High efficiency, safe output power dynamic compression function and temperature protection circuit eliminate user’s worry.
SPECIFICATIONS:
| PRODUCT MODEL | TK110A | TK112A | TK115A |
|---|---|---|---|
| RATED OUTPUT POWER | 200W | 300W | 400W |
| FREQUENCY RESPONSE | 60Hz-18KHz | 60Hz-18KHz | 55Hz-18KHz |
| SENSITIVITY | 95dB(1M/1W) | 97dB(1M/1W) | 98dB(1M/1W) |
| THD | <0.1% | <0.1% | <0.1% |
| SPL | 118dB | 122dB | 124dB |
| POWER SUPPLY REQUIREMENTS | AC 90-264V 45Hz-65Hz | AC 90-264V 45Hz-65Hz | AC 90-264V 45Hz-65Hz |
| DIMENTION | (302+214)*334*380mm | (349+245)*378*439mm | (443+336)*417*530mm |
