Help CenterActive Column Array Speaker
Related Products
Specifications
compact, small, crystal sound, active column speaker, modern design, reliable quality, easy to pack up, comprehensive protectionFeatures
lDigital Powered System
Two Digital power amplifiers are built in CL1501A sub cabinet and can output full range signals to drive CL0306 full-range speakers
l Switchable Crossover Frequency
Crossover frequency are switchable in three points, 100Hz/150Hz/200Hz
l More Accurate sound
Crystal clear high frequency, tight and strong low frequency, accurate sound reproduction, professional design ensure great specifications such as distortion, frequency response, convert rate, power supply band width and damping factor. This TC series amplifier adopts higher frequency convert to obtain high resolution of sound signal.
l Easy to stack up
Module design, flexible option based on applications, with bracket sockets on the top and bottom of CL0306 speaker for junction. Three kinds supporting hardware available: straight pole, support plate, wall bracket.
l Comprehensive Protection
1. Intelligent temperature controlled fans
2. Temperature Protection
3. Short-circuit, Over current Protection
4. DC Protection
5. Over/under- Voltage Protection
lWide Applications in various venues
Together with other C-Mark digital audio products such as digital mixer, network audio platform, to make up digital audio systems suitable for various applications.
C-Mark CL Series Active Array Column Speaker
CL0306 Full-range Speaker
Components 6 x 3” – 12Ω
Driving By CL1501A subwoofer
Rated Power 6 x 10W
Max. Power 120W
Impedance 8Ω
Frequency Response 180 - 15K Hz
Speaker Sensitivity 97dB (1m/1w)
Max SPL 108dB (1m)
CL1501A 15” Active Subwoofer
Components WLO15100X-4Ω
Amplifier Type Digital (Class D)
Power Supply AC 100 – 240V
50/60Hz
Rated Power 500W
Max. Power 1000W
Impedance 4Ω
Frequency Response 35Hz - 300Hz
Crossover Point 100/150/200 Hz switchable
Speaker Sensitivity 98dB (1m/1w)
Max SPL 128dB (1m)
