GYGF380T Pull-type Crack Filling Machine
1.Technical Parameters
Generator set |
18Kw |
Air compressor |
0.6m3/min |
Burner |
1.0×105cal/h |
Agitating motor |
0.75Kw |
Discharging pump motor |
1.5Kw |
Volume of sealant tank |
380L |
Length of spray gun hose |
5.5m |
Thermal oil volume |
200L |
Trailer |
PT-5 |
2.Performance Characteristics
1. Trailer
1) Trailer with low gravity center is safe in travelling.
2) Inertial mechanical braking system of trailer is reliable and sensitive.
3) The trailer height from ground is flexibly adjustable to match various tractors.
4) Independent suspension with rubber torsion rod is stable.
2. Imported burner is applied to this automatically controlled machine for safe and reliable performance. Good fogging effect of fuel leads to low fuel consumption and low noise. Fuel and air make perfect matching to keep stable burning conditions, high burning efficiency and little pollution to the environment.
3. Sealant discharging volume is regulated by frequency converter. Sealant is pumped without delay to minimize wear of material pump and prolong its service life. Return suction solves the problem of drop pollution to the pavement.
4. Discharging hose is electrical heated to prevent sealant blocking the hose, light, convenient and flexible in use.
5. All the unit of blowing, cleaning and heating concentrates in one system. Long-life imported air compressor is applied with advantages of energy saving, low noise and long service life.
6. Sealant tank is heated by means of thermal oil indirect heating. Vertical shaft beats the materials 360 degree, which makes sure it is free of blinder corner and temperature is uniform for the purpose of avoiding partial scorching and aging. Automatic temperature control system and digital display system are applied to guarantee stable and precise control to the temperature.
before after
3.Product Details
24hours service, welcome your inquiry and business visiting !
Professional and experienced technical service after sales !
Skype: cassie.yuxue
Henan Gaoyuan Road Maintenance Equipment Co., Ltd. was founded in 2004, and now is the TOP 3 companies in road maintenance equipment manufacturing industry of China.
We supply automatic asphalt distributor, synchronous chip sealer, fiber chip sealer, asphalt emulsion plant, intelligent asphalt rubber plant, intelligent micro surfacing paver (slurry paver), snow removal machines, municipal road management equipment and more to customers all over the world.
National High-way Maintenance Equipment Engineering Lab
In September 2012, the national development and reform commission approved the projectof National High-way Maintenance Equipment Engineering Lab. Two Lab buildings, a pilot workshop, the machine performance test site were built.By purchasing test equipment, test platform, multi-function integrated tester, It improved laboratory hardware advantage, strengthened personnel training and technology exchange, solved the technical bottleneck existed in road maintenance equipment.
Certification
Q1: What are the terms of payment.
A:Generally, L/C orT/T are used. that is 30% prepayent and 70% before shipping.
Q2: What about the warranty.
A;It would be for 12 months.
