Help CenterITC T-4120D Series 120W 240W 350W 500W 1U Digital Power Amplifier 4 Channel Quality Choice
Related Products
-
ITC T-4120D Series Hot Selling High Efficiency PA Digital AmplifierUS$ 500 - 1,000MOQ: 10 Units -
ITC T-4120D Series 85& Efficiency Switching Power 1U Digital Class D Amplifier PAUS$ 500 - 1,000MOQ: 10 Units
-
ITC T-4S60 Series 60W 120W 240W PA Sound System Used 4 Channel AmplifierUS$ 300 - 550MOQ: 30 Units
-
ITC T-6350 Series Audio Line Power 500W AmplifierUS$ 300 - 500MOQ: 10 Units
-
ITC T-6500 Series 350W 500W 650W Universal Stable Audio Speaker Power AmplifierUS$ 200 - 350MOQ: 30 Units
ITC T-4120D Series 120W 240W 350W 500W 1U Digital Power Amplifier 4 Channel
ITC T-4120D Series 120W 240W 350W 500W 1U Digital Power Amplifier 4 Channel
ITC T-4120D Series 120W 240W 350W 500W 1U Digital Power Amplifier 4 Channel
ITC T-4120D Series 120W 240W 350W 500W 1U Digital Power Amplifier 4 Channel
ITC T-4120D Series 120W 240W 350W 500W 1U Digital Power Amplifier 4 Channel
It’s class D power amplifier, which consist of 4 individual amplifiers. Optional rated power output include 120W, 240W, 350W and 500W. It’s designed in both tabletop and rack mount. Shinning feature is that it adopts tech. of power saving. And it’s with switching power so that the efficiency is up to 85%. Thermogenesis is less than 55 degree. It could operate stably at severe working condition. 4 balanced line input is in type of phoenix. 4 RJ45 port is for remote power control, volume control and working status monitor. Speaker output is at 100V with individual volume control. Indicators display signal, peak and protection status. Rational cooling system ensures the system to work under 55 degree. Complete protection is for overheat, overload and short.
ITC T-4120D Series 120W 240W 350W 500W 1U Digital Power Amplifier 4 Channel
* Class-D power amplifier.
* With switching power.
* Efficiency is up to 85%.
* Thermogenesis is less than 55 degree.
* In 1U.
* Optional rated power output includes 120W, 240W, 350W and 500W.
* 4 balanced line input is in type of phoenix.
* Speaker output is at 100V.
* With 4 RJ45 port for remote power control, volume control and status monitor.
* 4 speaker output is with individual volume control.
* Built in active band pass filter of 80Hz to 16KHz.
* With rational cooling system.
* With indicators displaying signal, peak and protection status.
* Complete protection for overheat, overload and short.
* Power supply is at AC 110V or 230V and DC 24V.
ITC T-4120D Series 120W 240W 350W 500W 1U Digital Power Amplifier 4 Channel
Model |
T-4120D |
T-4240D |
T-4350D |
T-4500D |
Rated Power Output |
4x120W |
4x240W |
4x350W |
4x500W |
Speaker Output |
100V |
|||
Input Sensitivity/Impedance |
±385mV/20KΩ, balanced phoenix connector |
|||
Overload Electromotive Force |
>11dB |
|||
Frequency Response |
80Hz~16KHz (+1, -3dB) |
|||
S/N Ratio |
≥85dB |
|||
THD |
≤0.1% at 1KHz, 1/3 rated power |
|||
RJ45 |
Remote power control, volume control and status monitor |
|||
Indicators |
Signal, peak, protection and power |
|||
Protection |
Overheat, overload & short |
|||
Cooling |
When Internal temp. reaches 55℃, the fan is turned on auto. |
|||
Power Consumption |
600W |
1200W |
1750W |
2250W |
Power Supply |
~110V/60Hz or ~230V/50Hz |
|||
Dimension |
484 x 395 x 44mm |
|||
Weight |
9.04Kg |
9.02Kg |
9.06Kg |
10Kg |
Quality?
Our products're applied to important event like Olympic Game Peking 2008, Asian Game Guangzhou 2010, etc.
Trustworthy?
We're not only popular supplier in China but has good reputation in the world.
In time?
We have the ability and we'll try our best to fulfill your demand.
Factory?
Welcome to NO.1 Building B Block Zhongcun Street Panyu Guangzhou China.
