ITC T-4S04 8 to 4 Professional Phono Preamplifier Hifi
ITC T-4S04 8 to 4 Professional Phono Preamplifier Hifi
ITC T-4S04 8 to 4 Professional Phono Preamplifier Hifi
1) 4 Mic/Line balanced input; the gain is adjustable; with attenuation switcher of -30dB and +48V phantom power switcher; with internal 80Hz HPF;
2) With 4 stereo AUX input and 4 balanced input; 4 balanced Internet signal input;
3) 4 Mic/Line balanced input and 4 stereo AUX input have independent control for volume and tone; the volume level of Internet signal is adjustable;
4) 4 balanced output and 1 auxiliar output;
5) With the priority function for Mic 1 and Mic 2; the threshold value of mute is adjustable;
6) Rear panel is with mute terminal; support online mute control.
ITC T-4S04 8 to 4 Professional Phono Preamplifier Hifi
Model |
T-4S04 |
Input Sensitivity/Impedance | |
1-4MIC/ Line |
2.5mV/5KΩ balanced, ±250mV/5KΩ balanced |
1-4AUX RCA In |
400mV/5KΩ unbalanced |
Output Level/Impedance | |
Master 1, 2, 3, 4 |
1V/600Ω balance (Max.:±7.75V) |
AUX |
1V/10KΩ unbalanced (Max.:7.75V) |
Tone |
Bass: ±15dB at 100Hz, Treble: ±15dB at 10KHz |
Low Cut |
200Hz / 12dB per octave slope |
Frequency Response |
20Hz to 20KHz |
S/N Ratio | |
MIC |
More than 60dB |
Line |
More than 75dB |
THD | |
MIC |
Less than 0.05% |
Line |
More than 0.03% |
Cross-talk | |
MIC |
More than 60dB |
Line |
More than 75dB |
Power Consumption |
20W |
Power Supply |
AC 110V/60Hz or AC 230V/50Hz |
Dimension |
484x200x44mm |
Weight |
3.9Kg |
