ITC T-60 Series Having 3 Level Priority Professional Power Mixer Amplifier
ITC T-60 Series Having 3 Level Priority Professional Power Mixer Amplifier
ITC T-60 Series Having 3 Level Priority Professional Power Mixer Amplifier
1) Professional PA Power Amplifier with Preamplifier
2) To do sound reinforce for small to large scale PA system
ITC T-60 Series Having 3 Level Priority Professional Power Mixer Amplifier
1) It’s in 2U rack mount case of 19” (Model: 60W T-60, 120W T-120, 240W T-240) and 3U rack mount case of 19” (Model: 350W T-350, 500W T-500, 650W T-650)
2) 3 Mic Input in Type of TRS, 2 AUX Input, 1 EMC Input
3) 2 Mic/Line Input (Sensitivity is 775mV)
4) 3 Level of Priority: Mic 1 has the highest prioriy, EMC has the second and others have the third
5) Mic 1/2/3 and AUX 1/2 have individual volume control; Treble/Bass control and total volume control are available
6) With complete protection circuit for short, overload, over-heat, etc
7) 2 ways of power output: Constant voltage output at 100V or 70V and Constant Impedance Output at 4 to 16 ohm
8) Power supply at DC 24V is also allowed for T-60, T-120, T-240 and T-350
ITC T-60 Series Having 3 Level Priority Professional Power Mixer Amplifier
Model |
T-60 |
T-120 |
T-240 |
T-350 |
T-550 |
T-650 |
Rate Power |
60W |
120W |
240W |
350W |
500W |
650W |
Output for Speaker |
70V, 100V or 4 to 16 ohm |
|||||
Sensitivity & Impedance for Input |
Mic 1/2/3: 5mV/600 ohm, Unbalanced TRS |
|||||
Line 2/3: 775mV/10Kohm, Unbalanced RCA | ||||||
AUX 1/2: 350mV/10Kohm, Unbalanced RCA | ||||||
EMC: 775mV/10Kohm, Unbalanced DG7.62 | ||||||
Sensitivity & Impedance for Output |
Mix Out: 1000mV/470 ohm, Unbalanced TRS |
|||||
Electric Potential of Overload |
Mic 1/2/3: >12dB, Unbalanced TRS |
|||||
Line 2/3: >12dB, Unbalanced RCA | ||||||
AUX 1/2: >20dB, Unbalanced RCA | ||||||
EMC: >12dB, Unbalanced DG7.62 | ||||||
Tone |
Bass: ±10dB at 100Hz |
|||||
Treble: ±10dB at 10KHz | ||||||
Frequency Response |
50 to 16KHz (+1dB, -3dB) |
|||||
S/N Ratio |
Mic 1/2/3: 66dB; AUX 1/2: 80dB |
|||||
T.H.D. |
1KHz: 0.5%, 1/3 Rated Power |
|||||
Mute |
Mic 1 has highest priority; Adjustment Range: 0 to 30dB |
|||||
Crosstalk |
≤50dB |
|||||
Cooling |
The Fan Starts, when Temp≥55-degree |
|||||
Circuit Protection |
Over-heat, overload & short |
|||||
Power Supply |
AC 110V/60Hz or AC 230V/50Hz or DC 24V |
AC 110V/60Hz or AC 230V/50Hz |
||||
Power Consumption |
100W |
200W |
400W |
500W |
750W |
950W |
Dimension |
484*303*88mm |
484*359*132mm |
||||
Weight |
8.1Kg |
8.6Kg |
11.68Kg |
13.96Kg |
15.72Kg |
17.8Kg |
Material |
Aluminum Alloy SPCC Case, Black |
|||||
