ITC T-4S60 Series Most Popular Made in China 4-input Audio Power Amplifier
ITC T-4S60 Series Most Popular Made in China 4-input Audio Power Amplifier
4 channel power amplifiers are designed for commercial and industrial public address application. 4 individual amplifiers are integrated in a single chassis and its rated power is optional including 60W, 120W and 240W per channel according to your demand. T-4S60/T-4S120 are in 2U while T-4S240 is in 3U.
Balanced line input is in phone jack. Constant voltage output of 70V, 100V and constant impedance output of 4-16ohm are provided for each channel by phoenix types, which is convenient for installation when matching different speaker.
Master volume control is included. Complete protection for over-heat, over-load, short-circuit. Indication for power, signal, peak and protection.
ITC T-4S60 Series Most Popular Made in China 4-input Audio Power Amplifier
* 4 individual amplifiers in 1 chassis;
* Rack mount amplifier in 2U(T-4S60/T-4S120) and 3U(T-4S240) type;
* Rated power is optional including 60W, 120W to 240W per channel
* Constant voltage output of 70V, 100V and constant impedance output of 4-16ohm are provided for each channel in phoenix;
* Isolated transformer for safe operation;
* Balanced line input in phone jack input for each channel;
* Reliable protection for over-heat, over-load, short-circuit;
* Indications for power, signal, peak, and protection
* Rational cooling device ensures working stably.
Optional
Power supplied at DC 24V is also allowed.
ITC T-4S60 Series Most Popular Made in China 4-input Audio Power Amplifier
Model | T-4S60 | T-4S120 | T-4S240 |
Rated Power Output | 4x60W | 4x120W | 4x240W |
Speaker Output | 70V, 100V & 4~16Ω | ||
Input Sensitivity & Impedance | ±385mV/10KΩ, Balanced phone jack type | ||
Overload Electromotive Force | >15dB | ||
Frequency Response | 50Hz~16KHz(+1dB, -3dB) | ||
S/N | >90dB | ||
THD | Less than 0.1% at 1KHz, 1/3 rated power | ||
Crosstalk | <50dB | ||
Cooling | Fan automatically start up when temp reaches 55℃ | ||
Protection | Over heat, over load, clip & short circuit | ||
Power Supply | ~110V/60Hz or ~230V/50Hz or DC 24V | ||
Power Consumption | 400W | 720W | 1500W |
Weight | 16Kg | 22Kg | 30Kg |
Dimensions | 484x448x88mm | 484x449x132mm | |
Finish | Panel: aluminum plate Case: steel plate | ||
ITC T-4S60 Series Most Popular Made in China 4-input Audio Power Amplifier
