ITC T-8000 8*8 Audio Matrix PA System Public Address System
ITC T-6760 Series IP PA System 60 Watt to 350 Watt IP Audio PA Amplifier
ITC T-8000 8*8 Audio Matrix PA System Public Address System
ITC T-8000 8*8 Audio Matrix PA System Public Address System
ITC T-8000 8*8 Audio Matrix PA System Public Address System
* The matrix & paging controller is highly integrated, which is cater for multi-zone paging and multi-sources selection. It’s complete solution for multi-zone, multi-functional venues like entertainment places, large-scale hotel, sports centers, shopping mall, airport etc.
* T-8000 provides with up to 8 music source input, 8 remote control panels, 2 remote paging consoles and 1 microphone input, all of these input couble be freely linked to different 8 zone output simultaneously.
* 1 remote paging console and 3 another remote control panels are available when expansion control, multi-zone paging and multiple audio sources is needed.
* The controller is expandable to 8*32 matrix system via CAT 5 cable to do cascade.
* With complete indication function.
* Each channel is provided with individual bass/treble control and volume control. Master volume and Monitor volume control is provided as well as.
* 8 fire alarm receiving port is equipped to activate internal alert.
* 3 kinds of pre-recorded audio including alert, evacuation message and alarm are provided.
* EMC port is for external voice alarm message.
* Both paging consoles and remote control panels are linked via standard CAT 5.
* 4 hot keys are for playing BGM and do paging in the whole area directly.
* Power supplied at AC 110V or 240V and DC 24V is also available.
* 5 levels of priority from high to low: Mic 1, fire alarm, remote paging console, remote control panel and background music.
ITC T-8000 8*8 Audio Matrix PA System Public Address System
Model |
T-8000 |
Line 1-4 Input |
195mV -2V/10KΩ |
Line 5-7 Input |
MIC: 5mV/600Ω, Line: 350mV3/10KΩ, Phantom Power: +48V |
Microphone 1 |
5mV-280mV/600Ω |
Remote Paging Station |
300mV-1.1V/10KΩ |
Remote Control Panel |
300mV-1.1V/10KΩ |
Tone Control |
100Hz-±10dB, 10KHz±10dB |
Output |
0.775V/600Ω |
Frequency Response |
MIC: 80Hz~18KHz(+1/-3dB), line: 20Hz~20KHz (+1/-3dB) |
EMC |
775mV/10KΩ |
S/N of Microphone |
>65dB |
Line of S/N |
>85dB |
Degree Of Separation |
>40dB |
Crosstalk |
>65dB |
THD |
<0.07% |
Indicator |
Power, Mic1, paging busy & monitor output |
Priority |
Mic1, voice alarm, local mic paging, remote zone paging, line 1-8 |
Communication Speed |
4800bps |
Communication Port |
RJ45 |
Communication Protocol |
RS485 |
Power Consumption |
20W |
Power Supply |
~110V/60Hz and ~ 240V/50Hz & DC 24V |
Dimensions |
484x304x132mm |
Weight |
6Kg |
