China Factory Direct Sales Low Noise High Speed Hydraulic Motor for Harvester Producer

Name: China Factory Direct Sales Low Noise High Speed Hydraulic Motor for Harvester Producer
Brand: Highland
SKU: 114868461

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Hydraulic Motors

Model Number:

MF20 hydraulic pump motor

Brand Name:

Highland

Ji'nan High Land Hydraulic Pump Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Type Hydraulic Motors

Model Number MF20 hydraulic pump motor

Brand Name Highland

Place of Origin Shandong, China

China manufacture hydraulic motor planetary gearbox for concrete mixer field

20 Series MF20/21/22/23 Variable Hydraulic Motor 20 series mf22 hydraulic motor of Mixers Trucks

Mixers Trucks 20 series hydraulic motor MF23/MV23

20 Series Hydraulic Fixed Displacement Motor

1. Heavy duty hydraulic piston motor

2. Completely interchangeable with original

3. Widely applicable for agricultrual machinery, engineering machinery, mining machinery,industrial machinery, aviation and transport machinery etc.

4. The hydrostatic hydraulic transmission drive in close system, consisting of PV20/21/22/23/24 serie heavy duty piston

pump and motor can work continuously with pressure 21Mpa under max. speed.

5. Peak pressure of system is up to 35Mpa, and min. pressure is 0.9Mpa higher than housing pressure.

6. Max. housing working presssure is 0.28Mpa.

7. Set pressure of charging relief valve of pump and motor are respectively 1.31-1.45Mpa and 1.10-1.24Mpa higher than

housing pressure, and max. oil temperature is 80°C

Technical Specification:

Model	Maximum displacement	Pressure/MPA		Max Speed(r/min)	Out put power when at 10MPA.1500r/min)/KW	Variable pump


		Rated	Max			Flow at maximum speed(L/min)	Charge pump displacement(ML/R)	Weight/kg


20	33.3	21	35	3590	8.2	119.54	12.3	45
21	51.6	21	35	3500	12.7	180.6	16.2	53
22	69.8	21	35	2810	17.2	196.14	18.03	63
23	89	21	35	2590	21.9	230.51	18.03	78
