Reliable Factory Supplier 12v Piston Pump PV22 Hydraulik Pump

  Reliable factory supplier 12v piston pump PV22 hydraulik pump

 Application Range:

This product is 20 series hydraulic transmission system introduced form American company. It is closed hydraulic system made up

of axial hydraulic pump and motor. The pump is variable pump with charge pump and the motor is fixed-displacement or variable-

displacement motor with valve assy.  The control way of changing displacement includes MDC, HDC and EDC which can

efficiently control the discharge, direction and power of the output oil. The hydraulic transmission system made up of this series of

pump and motor has features of wide work range, reliable working state, easy operation and can be widely used on the hydraulic

apparatus of engineering machine, agricultural machine, mine machine, aviation and transport machine.

Hydraulic Pump of PV20 Axial Piston Variable Displacement Pump  Fetures:

1. Series 20 Axial Piston Variable Displacement Pumps are well engineered and easy to handle.

2. The full-length shaft with a highly efficient tapered roller bearing arrangement offers a high loading capacity for external radical forces.

3. The pumps can be connected with other additional pumps.

4. The hydro-mechanical servo displacement control maintains the selected swash plate position and hence pumps displacement.

5. Upon release of the control handle, the swash plate automatically returns to zero position and the flow reduces to zero.

6. High case pressures can be achieved without leakage even at the lowest temperatures by using suitable shaft seals.

7. The servo valve arrangement offers the facility to incorporate function regulators and remote control systems.

8.Axial piston units are designed for easy servicing. Complete dismantling and reassembly can be carried out with standard hand tools, and all components or sub-assemblies are replaceable.

High Land Hydraulic Pump Co.,Ltd owns strong ability of R & D, first-class scientific management elites and advanced equipment

for manufacturing and testing, is a professional and high-tech enterprise.

Main Products:

Hydraulic Pump

Hydraulic Comprehensive Test Bench

Digital Hydraulic Test Bench

MYHT Portable Hydraulic Tester

Hydraulic Pump Parts

If any products interest you,please don't hesitate to send us your inquiry,we will give you our best and favourable reply!

Any question,please feel free to contact us.
