Soundproof and Weatherproof PDG-150S Diesel Generator

Name: Soundproof and Weatherproof PDG-150S Diesel Generator
Brand: Powercity
SKU: 114852689
Availability: InStock

US$ 15,000 - 15,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Powercity

Model Number:

PDG-150S

Powercity Electromechanical & Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

XIAMEN CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Powercity

Model Number PDG-150S

Output Type AC Three Phase

Speed 1500/1800

Frequency 50/60

Rated Power 110/132

Rated Voltage 200~240/380~440

Rated Current 150

Specifications

Soundproof and weatherproof PDG-150S Diesel Generator
1.Stable voltage output,
2.Low fuel consumption
3.Quiet operation

Soundproof and weatherproof PDG-150S Diesel Generator

1. With Fan Cooling, Self regulating

2. Optimized ventilation design makes generator ventilation well

3. Heavy duty performance

4. Combustion air filter with washable element to prolong engine life

5. Integrated artificial intelligence

SPECIFICATIONS
MODEL		PDG-150S
• ALTERNATOR
Make & Model		POWERCITY SLG-274E
Frequency	Hz	50	60
Output Rating (KVA)	Continuous	125	150
	Standby	137.5	165
No. of Phases		3-Phase (4 Wires)
Rated Voltage	V	200~240 / 380~440
Power Factor		0.8 (Lagging)
Voltage Regulation	%	Within +/- 1.5
Excitation		Brushless, Rotating Exciter (with A.V.R.)
Insulation		Class H
• ENGINE
Make & Model		YUCHAI YC6A180Z
Type		Vetical Inline, Water-cooled, 4-Stroke Direct Injected,Turbo-Charged

Output Rating	Kw/rpm	110/1500	132/1800
No. of Cylinders-Bore x Stroke	mm	6 - 108 x 132
Piston Displacement	L	7.252
Fuel		ASTM No.2 Diesel Fuel or Equivalent
Fuel Consumption @75% load	L/h	18.7	22.4
Lube Oil Capacity	L	22
Coolant Capacity	L	47.25
Battery Capacity	V-Ah	12V-120Ah (2pcs)
Fuel Tank Capacity	L	250
• UNIT
Dimensions	Length mm	3095
	Width mm	1110
	Height mm	1660
Dry Weight	kg	2410
• SOUND LEVEL
dB @ 7m		73	75
