Specifications
1.G2512 laser cutting and engraving machine2.80-150w
ing area:2500x1200mm
4.capacity:120 sets/month
5.CE, FDA,
G2512 laser cutting and engraving machine
Advantage
Our own developed and designed die cutting laser machine adopts high-performance 80w-200w hermetic laser(80/100/130/150w). it changes the traditional low-precision and slow-speed shortcomings in sawing and improves working efficiency, which can meet high- precision demand for all clients. This kind of model integrates lasers, precise machinery, computer-controlled technology to process, the user only needs to input parameters to computer, then machine will work automatically.
Applicable Materials
Wooden board, acrylic, MDF, food packaging, air model, building models and other non-metal materials.
Applicable Industry
The machine is suitable to professional user for cutting performance in template, package, advertisement model, building upholster, fitment and other industries.
Technical Parameter
Laser power |
80/100/130/150/200W(optional) |
Laser type |
Hermetic CO2 glass tube |
Power supply |
AC220±10% 50HZ AC110±10% 60HZ |
Working area |
2500*1200mm |
Max moving speed |
0-25000mm/min |
Worktable |
Honeycomb worktable/aluminium knife(optional) |
Locating Precision |
<0.01mm |
Min Shaping Character |
Character:3*3mm. Letter:2*2mm |
Operating Temperature |
5-35°C |
Resolution Ratio |
≤4500dpi |
Control Configuration |
DSP |
Data Transfer Interface |
USD(offline) |
System Environment |
Windows2000/WindowsXP/Vista/Win7 |
Cooling way |
Water cooling and protection system |
Graphic Format Supported |
The files which CoreDraw, Photoshop, AutoCAD can identify(BMP, GIF, JPEG, PCX,TGA, TIFF, PLT, CDR, DMG, DXF, PAT, CDT, CLK, DEX, CSL, CMX, AI, WPG, WMF, EMF, CGM, SVG, SVGZ, PCT, FMV, GEM,CMX) |
Compatible software |
CoreDraw, AutoCAD |
Cutting thickness |
0-25mm/30mm(depends on different materials) |
Color Separation |
Separation of cuuting up to 256 colors |
Sloping Engraving |
Yes, slop can be designed discretionarily |
Cuts off the water supply the protection |
yes |
Net weight/Gross weight |
580/700kg |
Machine Dimension |
2700*1830*1000mm |
Package Dimention |
2980*1900*1530mm |
Optional Parts |
High-grade cooling system/imported focus lens/double head/cylinder rotary attachment/irregular rotary attachment |
