Home > Manufacturing & Processing Machinery > Machine Tools > Milling Machine > X6336WA Universal Turret Milling Machine
X6336WA Universal Turret Milling Machine
US$ 9,600 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
China
Brand Name:
LINUO
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
X6336 Automatic Feed Universal Milling MachineUS$ 8,000 - 9,200MOQ: 1 Set -
New Products Universal Milling Machine LM-1460US$ 8,000 - 12,000MOQ: 1 Set
-
X6332B Milling MachineUS$ 8,000 - 10,000MOQ: 1 Set
-
XQ6232A Universal Milling MachineUS$ 3,500 - 7,000MOQ: 1 Set
-
XQ6232A Factory Manufactured Vertical Milling MachineUS$ 3,500 - 7,000MOQ: 1 Set
Condition
New
Place of Origin
China
Brand Name
LINUO
Model Number
X6336WA
Type
Other, Universal, Drilling Rig
CNC or Not
Normal
Voltage
380V
Power(W)
4kw
Dimension(L*W*H)
2000x2000x2250 mm
Weight
2850 kg
Certification
CE
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
X6336WA universal turret milling machine :
1Taiwan high speed milling head, 5HP.
2Work table can turn 45 degrees.
3Processing of a wide range.
4Three axes automatic feeds.
5Large torque and strong power, 2HP,fast-moving 2000mm/min.
6The fuselage and the lifting platform for the square guide.
Specification |
X6336WA |
Spindle taper |
ISO 40 vertical ISO 50 horizontal |
Distance from vertical axis to table surface |
135-485 mm |
Distance from horizontal axis to table surface |
0-350 mm |
Spindle speeds range |
75-4540 rpm vertical 60-1800 rpm horizonal |
Table size |
1500x360 mm |
Max.table travel |
900x400x405 mm |
Horizontal motor power |
4.0 kw |
Vertical motor power |
3.7kw (V) 2 kw (H) |
Overall dimensions |
2000x200x2250 mm |
N.W/G.W |
2650/2850 kg |
