Home > Products > Milling Machine > X6325B china radial milling machine
X6325B china radial milling machine
- 50 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | LINUO | Model Number | X6325B | |
| Type | Vertical | CNC or Not | Normal | |
| Voltage | 380V | Power(W) | 2.25KW | |
| Dimension(L*W*H) | 1516x1550x2080mm | Weight | 1400kg | |
| Certification | CE | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
X6325B china radial milling machine
Parameters of our specification of vertical miling machine:
| Model | X6323A | X6323B | X6325A | X6325B | X6325 | X6325C | X6325D | X6330 | X6330A | X6333 | X6333A | |
| Table size | 230*1067 or 230*1246 | 254*1270 or 254*1370 | 254*1270 or 254*1370 | 305*1370 or 305*1500 | 330*1370 or 330*1500 | |||||||
| Long travel | 650 840 | 850 950 | 850 950 | 870 1000 | 840 1000 | |||||||
| Cross travel | 305 | 400 | 420 | 380 | 368 | |||||||
| Vertical travel | 400 | 420 | 420 | 430 | 450 | |||||||
| T-slot No. and size | 3*16 | |||||||||||
| Ram travel | 312 | 470 | 500 | |||||||||
| Distance from spindle nose to table surface | 15-415 | 0-420 | 0-435 | 0-450 | ||||||||
| Spindle hole taper | standard:R8 Optional:ISO30/ISO40 | Std:ISO40 | Std:ISO40 | |||||||||
| Spindle travel | 127 | |||||||||||
| Spindle speed | 16(shiftgrade): 50HZ65-4500 | 16(shiftgrade): 50HZ65-4500 | 16(shiftgrade): 50HZ 65-4500 | |||||||||
| Optional:variable 65-4500 | Optional: variable 65-3750 | Optional:variable 65-3750 | ||||||||||
| Auto.quill feed | Three grades:0.04(0.0015")/0.08(0.003")/0.15(0.006") | |||||||||||
| Spindle motor | 2.25kw/3hp | 3.75kw/5hp | 3.75kw/5hp | |||||||||
| Head swivel | 90° | |||||||||||
| Head tilting | 45° | fixed | 45° | fixed | 45° | fixed | ||||||
| Package | 1set/case | 1400x1476x2030 | 1516x1550x2080 | 1566x1650x2080 | 1800x2016x2180 | |||||||
| 2sets/case | 1450x1570x2080 | 1650x1790x2170 | 1720x1800x2175 | 1800x2200x2180 | ||||||||
| 3 sets/case | 1450x2180x2080 | 1650x2285x2235 | ||||||||||
| N.W./SET | 1100 | 1160 | 1380 | 1420 | 1550 | 1590 | 1590 | 1700 | 1750 | 2300 | 2350 | |
Lianyungang Linuo Machine Tool Co.,ltd is a leading high-tech enterprise and manufacture in China for High end machine tools, has strong technical team covering full technical field.
which is specializes in exporting all kinds of machinery,such as grinding machines,CNC machine centers,CNC & universal lathes,CNC & universal milling machines,radial drilling machines,and cnc wire cutting edm machines etc.
Lianyungang Linuo Trading Co.,ltd is a Import & Export company,which is the branch company for international business.
We sincerely hope to establish a long-term cooperative relationship with you and become your true partner when you need our service.
Contact Us
- Lianyungang Linuo Trading Co., Ltd.
- Contact nameNicole Yuan Chat Now
- Phone86-0518-85683918
- AddressNo.109,New Eastern Road,Development Zone, Lianyungang, Jiangsu
