Specifications
1.cylindrical grinding2.Cross liner guideway more efficient
3.Converter headstock & Easy operation
cylindrical grinding
Features:
The M13 series universal cylindrical grinders are one of the most important products . We started our career by manufacturing the cylindrical grinders. For these years we have supplied many high quality cylindrical grinders for domestic and abroad market.
M13series type universal cylindrical grinding machines are used for grinding external or internal surfaces of rotary work-pieces of cylinder and taperworkpiece in almost every country all over the world because of the high quality with competitive price.
The longitudinal movement of the worktable is driven by hydraulic or by hand wheel. The worktable can rotate to a certain degree so as to be suitable for grinding taper.
The wheel head cross feed is driven by hydraulic, which realizes automatic periodical feed and rapid feed. It can also do rough and fine feed through hand wheel.
Our universal cylindrical grinder has already passed the strict CE certification and had already got the CE certificate. Our factory also get the ISO management system certificate.
Specifications and Technical Parameters
| item/model | unit | M1332 | ||
| General capacity | Distance between centers | mm | 500,750,1000,1500,2000,3000 | |
| Center height | mm | 180 | ||
| Dia.ground (O.D.) | mm | 8-320 | ||
| Max.length ground (O.D.) | mm | 500,750,1000,1500,2000,3000 | ||
| Max.weight of workpiece | kg | 150 | ||
| workhead | Center taper | MT | 5 | |
| Spindle speed | r/min | 50HZ:25-380 | ||
| wheelhead | Wheel spindle speed | rpm | 1100 | |
| Wheelhead rapid travel | mm | 50 | ||
| max.travel | mm | 235 | ||
| Hand feed per.rev. | mm | rough:2 fine:0.5 | ||
| Hand feed per gra. | mm | rough:0.01 fine:0.0025 | ||
| Weel size ( O.D.* W *D) | mm | 600*75*305 | ||
| Peripheral velocity | m/s | |||
| table | Hand feed per rev. | mm | 6 | |
| Max.Swiveling angle of table | clockwise | ° | 3°(500,750,1000,1500) 2°(2000,3000) | |
| Anti clockwise | ° | 9°(500)8°(750)7°(1000)6° (1500)5°(2000)3°(3000) | ||
| Longtidual speed range of table | m/min | 0.1-4 | ||
| tailtock | Center taper | MT | 4 | |
| Quil travel | mm | 30 | ||
| motor | Wheelhead motor power | kw | 11 | |
| Workhead motor power | kw | 1.5 | ||
| machine | Gross weight | T | 4(500),4.2(750),5.3(1000),6.1(1500),7.9(2000).9.9(3000) | |
| Packing dimension | cm | 2600*2000*2050(500) 3000*2000*2050(750) 3380*2000*2050(1000) 4380*2000*2050(1500) 5400*2000*2050(2000) 7390*2000*2050(3000) | ||
Standard accessories:complete set of eletrical equipment, coolant equipment, wheel periphery dresser, wheel flange, wheel balancing arbor, leveling wedge, open-type steady rest, internal grinding attachment.
Optional accessories: Balance stand, Close steady rest, Radius wheel dresser, End wheel dresser, Coolant tank with magnetic seperator, coolant tank with magnetic seperator and paper filter.
The work head spindle, wheel head spindle, internal grinding spindle, coolant pump, hydrodynamic and hydrostatic oil pump are driven by separate motors.
Each moving parts of the machine has electric, hydraulic and mechanic interlock structure machine is well designed with pleasing appearance, all control lever are centralized in panel make operating easy
The wheel dresser can be assembled on the worktable surface or on the tailstock.
From the above Our M13 series universal cylindrical grinder is good looking and practical.
The milling machines are packed by the fumigation wooden pallet which is easy for clients to transport or load and unload.
