MA6025Q Universal Tool Cutter Grinder Manufacture

MA6025Q Universal Tool Cutter Grinder Manufacture thumbnail-1
MA6025Q Universal Tool Cutter Grinder Manufacture photo-1
US$ 4,000 - 7,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Universal
CNC or Not:
Normal
Contact Supplier Request Quote Chat Now
Lianyungang Linuo Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Universal
CNC or Not Normal
Max. Grinding Diameter 16mm
Max. Grinding Length 100mm
Place of Origin Chongqing, China
Brand Name LINUO
Model Number MA6025Q
Voltage 380V
Power(W) 3.15kw
Dimension(L*W*H) 1790x1520x 1640mm
Weight 1250kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.MA6025Q universal tool cutter grinder manufacture
2.high quality
3.include all accessories
petitive price

MA6025Q  universal tool cutter grinder manufacture



1.The series machine are specially suitable for sharpening tools in HSS, tungsten carbide and other materials, also for

cylindrical, surface, slot and profile grinding work.

2.By using additional attachments, you greatly extend the range of application of there machinery and can solve individual

machining problems, such as grinding of various hobs, for tools, spherica cutters, twist drills and steep taper reamers, etc.

3.The series machine wheelhead with two-dimensional setting , workhead stock swivels with double dir.,

4.And supplied with ISO-50 taper hole.

5.Worktable is supported in preloaded ball guide and can be driven by hand or by infinitely changing rate hydraulic.


MQ6025A Technical Data:




Max. swing dia. of workpiece

  250mm



 Max. distance between centers

  650mm



 Area of the operating table

   940*135mm



 Max. longitudinal travel of table

  480mm



 Max. swing angle of table

  :±60degree



 Max travel of wheel head cross wertical

  230mm



 Max. swing angle of wheel head in horizontal plane in vertical plane

  360degree



Max. swing angle of wheel head in the longitudinal plane in vertical plane

  30degree±15degree



 The taper of the spindle end

  MT NO.3



 Main motor power

  50Hz,0.75/1.1KW



 The Speed of Grinding wheel

  1400/2800RPM



 The speed of Motor

  3050/6095RMP



 The Motor of Cylindrical grinding attachment

  50Hz,0.12KW



 The size of the machine

  1460*1102*1240mm



 The weight of the machine

  1000kg

 standard accessories:





Model

Description

1

Work head (main body of work head including turning base)

2

T-bolt for work head

3

Left-hand tailstock

4

T-bolt for left-hand tailstock

5

T-bolt for right-hand tailstock

6

Right-hand tailstock

7

Draw-in bolt for work head

8

Draw-in bolt washer

9

Double-end wrench (17x21)

10

Nut wrench

11

Cross-screw driver

12

Wrench bars for hexagonal holes

13

Center gauge (including center height indicating piece)

14

T-wrench for grinding wheel sleeve

15

Sleeve extracting bar

16

Collet wrench

17

Pin wrench

 MA6025Q universal tool cutter grinder manufactureMA6025Q universal tool cutter grinder manufacture
