Specifications
Fingerprint Access Control Keypad1. Supports 18 languages
2. Fingerprint capacity:1000
3. USB flash disk, RS485& TCP/IP
Product Description
S20 is a specialized security & protection system device facing towards small and medium enterprises, and it integrates multiple functions, such as fingerprint identification, door lock monitoring, anti-theft alarm, access control and attendance record, reliable quality, voice prompt, multi-language system, human-machine interface, excellent communication function, comprehensive software for background data processing.
It supports various databases and time-based grouping function for access control, and achieves easy operation, good applicability and excellent performance. This product is applicable to office building, warehouse, confidential department, archives, computer room and intelligent residential district.
Main Features:
1. Excellent industrial design and graceful appearance
2. Special fingerprint sensor for quick response and activation
3. 32-bit CPU with low power consumption and high processing speed
4. Creature V1.0 core algorithm for fast and accurate comparison
5. Multiple communication modes via USB, RS485 & TCP/IP for data transmission
6. Support data upload/download via USB flash disk
7. Wiegand output, alarm signal output, relay output, door sensor signal interface, compatible with all standard access controllers
8. Optional card reading module for combining card identification with fingerprint identification
9. Multiple identification modes to ensure data integrity and security, i.e. via fingerprint only, card only, or card + fingerprint
10. Fingerprint capacity: 1,000
11. Excellent industrial design and graceful appearance.
| Item | Details |
| CPU | 32-bit ARM |
| Fingerprint sensor | Subminiature optical fingerprint scanner |
| Fingerprint activation method | Capacitive sensing |
| Fingerprint collecting area | 17mm*19mm |
| Fingerprint capacity | 1,000 |
| Card capacity | 1,000 |
| Comparison mode | Fingerprint, card, password, password + fingerprint,fingerprint + card |
| Identification time | < 1 second |
| Communication interface | USB flash disk, USB, RS485 & TCP/IP |
| Prompt tone | Human voice |
| Electric lock | Direct control |
| Relay | DC 12V |
| Wiegand | Wiegand 26/34 output |
| Door sensor | 1-call detection |
| Alarm | Against tampering, door unclosed & unauthorized opening, 1-call alarm signal output (other alarms can be customized) |
| Shell | ABS |
| Operation temperature | -15℃~65℃ |
| Dimensions | 140mm * 105mm * 35mm |
