Mini PLC Splitter 1*8 Steel Tube 0.9mm Fiber Optic Splitter for FTTH

Mini PLC Splitter 1*8 Steel Tube 0.9mm Fiber Optic Splitter for FTTH photo-1
US$ 5 - 15 MOQ: 10 Pairs
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Atongda ,OEM
Model Number:
ATD- PLC-W1-8
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Atongda ,OEM
Model Number ATD- PLC-W1-8

mini PLC splitter 1*8 steel tube 0.9mm fiber optic splitter for FTTH

Steel tube type plc splitter Specifications

1)low IL&PDL
2)uniformity&high reliability
3)1260~1650nm wavelength
4) Steel Tube PLC  Splitter :1x2,1x4,1x8,1x16,1x32,1x64,2x2,2x4,2x8,2x32,2x64

Planar lightwave circuit PLC splitter is a type of optical power management device that is fabricated

using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength
range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal
power splitting. We provides whole series of 1xN and 2xN splitter products that are tailored for specific applications.

Steel tube type plc splitter Features:

Good uniformity and low insertion loss
Low Polarization Dependent Loss
Excellent Environmental Stability
Excellent Mechanical
Stability Telcordia GR-1221 and GR-1209

Steel tube type plc splitter Application:
Fiber to The Home (FTTH)
Passive optical networks (PON)
Local Area Networks (LAN)
Cable Television (CATV)
Test Equipment


Specification

Parameter

Specification

Unit

Remark

Ports

1×8



Reach RoHS requirements

Operation wavelength

1260~1650

nm

Insertion Loss

≤10.7

dB

PDL

≤0.3

dB

Uniformity

≤0.8

dB

Return Loss

50

dB

Directivity

≥55

dB

Fiber type

G657A



Pigtail length

≥1.0

m

Connector type

-



Fiber Logo

-



Material of tube

input&output Φ0.9 white losse tube



Package Size

(L)*(W)*(H)

60*7*4

mm

Working temperature

-40~+85

Storage Temperature

-40~+85

Note: The Il was tested under room temperature with connector . Without connector, the IL should reduce 0.2dB.

System Design

 mini PLC splitter 1*8 steel tube 0.9mm fiber optic splitter for FTTH



Production Show





Certificate

mini PLC splitter 1*8 steel tube 0.9mm fiber optic splitter for FTTH



Shipment

mini PLC splitter 1*8 steel tube 0.9mm fiber optic splitter for FTTH

Payment

mini PLC splitter 1*8 steel tube 0.9mm fiber optic splitter for FTTH
