SZS Series Coal Water Slurry Fired Steam Boiler

Name: SZS Series Coal Water Slurry Fired Steam Boiler
Brand: Yunna
SKU: 114759901
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Natural Circulation

Usage:

Industrial

Wuxi Yunna Materials Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Natural Circulation

Usage Industrial

Structure Water Tube

Fuel Coal-fired

Place of Origin Jiangsu, China

Brand Name Yunna

Model Number SZS

Output Steam

Certification ASME; ISO9001

After-sales Service Provided Engineers available to service machinery overseas

SZS series coal water slurry fired steam/hot water boiler

Steam boiler:evaporation capacity:2-20t/h,pressure:1.0-2.5MPa

Model	SZS4-1.25-J	SZS6-1.25-J	SZS10-1.25-J	SZS15-1.25-J	SZS20-1.25-J
	SZS4-1.6-J	SZS6-1.6-J	SZS10-1.6-J	SZS15-1.6-J	SZS20-1.6-J
	SZS4-2.5-J	SZS6-2.5-J	SZS10-2.5-J	SZS15-2.5-J	SZS20-2.5-J
Rated evaporation capacity(t/h)	4	6	10	15	20

Rated working pressure(MPa)	1.25/1.6/2.5	1.25/1.6/2.5	1.25/1.6/2.5	1.25/1.6/2.5	1.25/1.6/2.5

Rated steam temperature(°C)	193/204/226	193/204/226	193/204/226	193/204/226	193/204/226

Water-supp;y temperature(°C)	20	60	60	104	104

Boiler efficiency(%)	>84	>86	>86	>86	>86

Applicable fuel	coal water slurry

Draught fan	YX9-35 No.8C 22kw	GY6-1 30kw	GY10-15 55kw	Y5-47 12D 75kw	Y5-47 12.4D 90kw

Blower	T4-72 4.5A 7.5kw	T4-72 5A 11kw	GG10-1 15kw	G4-73 9D 30kw	G4-73 9D 37kw
Slurry pump	XP030B12JA 1.5kw	XP035B12JA 2.2kw	XP040B12JA 4kw	XP040B12JA 4kw	XP050B12JA 5.5kw

Hot water boiler:delivered heat:1.4-14MW,pressure:0.7-1.25MPa

Model	SZS2.8-1.0/95/70-J	SZS4.2-1.0/95/70-J	SZS7-1.0/115/70-J	SZS10.5-1.0(1.25)/115/70-J	SZS214-1.0(1.25)/115/70-J

Rated heating power (MW)	2.8	4.2	10	15	20

Rated water-delivery pressur(MPa)	1	1	1	1.0/1.25	1.0/1.25

Rated outlet temperature (°C)	95	95	115	115	115

Rated inlet temperature (°C)	70	70	70	70	70

Circulation amount(m³/h)	48	144	133	200	267

Boiler efficiency(%)	>85	>86	>86	>86	>86

Applicable fuel	coal water slurry

Draught fan	YX9-35 No.8C 22kw	GY6-1 30kw	GY10-15 55kw	Y5-47 12D 75kw	Y5-47 12.4D 90kw

Blower	T4-72 4.5A 7.5kw	T4-72 5A 11kw	GG10-1 15kw	G4-73 9D 30kw	G4-73 9D 37kw

Slurry pump	XP030B12JA 1.5kw	XP035B12JA 2.2kw	XP040B12JA 4kw	XP040B12JA 4kw	XP050B12JA 4kw
