SC Cable Lugs
- 50000000 Piece / Pieces per Month
- NINGBO SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Dixsen | |
| Model Number | SC | Type | Lug |
Product Description
Specifications
A.section 1.5-1000mm2B.SC,JGA,JGK
C.ISO9001,14001,CE,ROHS
D.manufacturer
E.430 employees,15000 square meter factory
SC copper lug/cable lug/connecting terminal
These products are suitable for the connection of copper conductors(section 1.5-1000mm2) in power cable with electronic equiment they are made of with higher 99.9% pure copper tube T2 and coated with ing temperature-55oC-150oC.
| φ | D | d | L |
SC(JGA)-1.5 | φ4.2,φ5.2 | 3.5 | 1.8 | 18 |
SC(JGA)-2.5 | φ4.2,φ5.2,φ6.2 | 4 | 2.5 | 19 |
SC(JGA)-4 | φ5.2,φ6.2 | 4.8 | 3.1 | 21 |
SC(JGA)-6 | φ5.2,φ6.2,φ8.2 | 5.5 | 3.8 | 24 |
SC(JGA)-10 | φ6.2,φ8.2 | 6.8 | 4.8 | 25.5 |
SC(JGA)-16 | φ6.2,φ8.2,φ10.5 | 7.5 | 5.5 | 30.5 |
SC(JGA)-25 | φ6.2,φ8.2,φ10.5 | 9 | 7 | 34 |
SC(JGA)-35 | φ6.2,φ8.2,φ10.5,φ12.5 | 10.5 | 8.2 | 38 |
SC(JGA)-50 | φ8.2,φ10.5,φ12.5 | 12.5 | 9.8 | 45 |
SC(JGA)-70 | φ8.2,φ10.5,φ12.5 | 14.5 | 11.5 | 50 |
SC(JGA)-95 | φ10.5,φ12.5 | 17.5 | 13.8 | 55.5 |
SC(JGA)-120 | φ12.5,φ16.5 | 19.5 | 125.5 | 63 |
SC(JGA)-150 | φ12.5,φ16.5 | 21 | 16.5 | 71 |
SC(JGA)-185 | φ16.5 | 23.5 | 18.8 | 18 |
SC(JGA)-240 | φ16.5 | 26.5 | 21 | 92 |
SC(JGA)-300 | φ16.5,φ20.5 | 30 | 24 | 102 |
SC(JGA)-400 | φ16.5,φ20.5 | 34 | 26.5 | 113 |
SC(JGA)-500 | φ16.5,φ20.5 | 38 | 30 | 123 |
SC(JGA)-630 | φ20.5 | 45 | 35 | 135 |
SC(JGA)-800 | φ22.5 | 50 | 39 | 170 |
SC(JGA)-1000 | φ22.5 | 56 | 44 | 200 |
...
