AC Ventilation Fan 120X120X38 115V,230V,380V

AC Ventilation Fan 120X120X38 115V,230V,380V thumbnail-1
AC Ventilation Fan 120X120X38 115V,230V,380V photo-1
US$ 0.1 - 10 MOQ: 1 Piece
Key Specifications
Get Latest Price
Electric Current Type:
AC
Blade Material:
Plastic
Mounting:
Other, SCREW
Contact Supplier Request Quote Chat Now
Zhejiang Dixsen Electrical Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
CHINA PORT
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type AC
Blade Material Plastic
Mounting Other, SCREW
Place of Origin Zhejiang, China
Brand Name DIXSEN
Model Number RC
Power 20,25
Voltage 115,230,380V
Air Volume 108CFM/3.05CMM,ETC
Speed 2500,2900
Certification CE

Specifications

A.Founded in1980
B.CE,ROHS,SGS,UL,KEMA,VDE,TSE,CB
C.ISO9001,14001
D.manufacturer
E. 430 employees,15000 square meter factory

AC Axial Fan(AC Fan, Axial AC Fan, Axial Fan, Fan Motor,AC Cooler Fan,AC Cooling Fan,Ventilation Fan)(80X80X25,80X80X38,92X92X25,110X110X25,120X120X25,120X120X38,135X135X38,150X150X51,150X170X52,172X51,180X180X60,200X200X60,220X60)

Model: RC120-38

Size:120x120x38mm

Voltage: AC ,110V / 220V / 380V

Frequency: 50Hz / 60Hz

Weight:515g


Electric motor: Shaded pole type AC electric motor design
Frame: High quality aluminum alloy, anti-corrosive and moisture proof structure
Impeller: UL94V-0 70%  PBT+30%FRP
Bearing:  Ball Bearing or Sleeve Bearing
Insulation: Class B
Insulation Impedance: The case adds 500V DC to the coils, insulation impedance 100MΩ        higher
Dielectric strength: 0.5mA 1500V AC /min
Safety protection: Impedance protection
Operating temperature: -10~70
Storage temperature: -40~70

Model

Dimension

mm

Voltage V AC

Frequency Hz

Current

AMP

Power

Watts

Speed

RPM

Air Flow

CFM

Pressure

mm H2O

Noise

dBA




RC120-38L-115

120x120x38

115

50

0.25

25

2500

87

0.23

46.5



RC120-38M-115

60

0.23

20

2900

108

0.28

52.6



RC120-38L-230

230

50

0.14

25

2500

87

0.23

46.5



RC120-38M-230

60

0.12

20

2900

108

0.28

52.6



RC120-38L-380

380

50

0.14

25

2500

87

0.23

46.5



RC120-38M-380

60

0.12

20

2900

108

0.28

52.6



AC Ventilation Fan 120X120X38 115V,230V,380V



 AC Ventilation Fan 120X120X38 115V,230V,380V

AC Ventilation Fan 120X120X38 115V,230V,380V

AC Ventilation Fan 120X120X38 115V,230V,380V



2. Packing show

AC Ventilation Fan 120X120X38 115V,230V,380V



3. Company show

AC Ventilation Fan 120X120X38 115V,230V,380V





 AC Ventilation Fan 120X120X38 115V,230V,380V



4. Production series

AC Ventilation Fan 120X120X38 115V,230V,380V

...
