10'' 5.0 Micron PP Filter cartridge
Description:
E007-PP filter cartridges are filter cartridges constructed of polypropylene fine fiber. This PP filter cartridges is tested and certified by NSF International against NSF/ANSI Standard 42 for material requirements only. They are capable of high dirt-holding capacity, high flow rates and broad chemical compatibility. Due to their features, they are ideal and most cost-effective for the wide range of prefiltration for water treatment industry.
Specifications
PP filter for reverse osmosis water filter, for Pre-filtration water for kitchen. office, laboratory. etc.
This product by purely physical filtration, with water pressure for normal using, do not need power to run, it can effectively hold up the impurities which are bigger than 5 micron, so to reduce the burden on other filters behind, and extend its life.
Outer shell material: PP(polyropylene)
Filter material: PP(food grade)
Filter Precision: 5 micron
Service life: 8000-11000L
Max Temperature: 5-45℃
Max Pressure: ≤0.4Mpa
Max outlet: 2.5L/Mim
Max flow: 3L/Min(0.2Mpa, 25℃ )
Note:
1. Inlet condition: Municipal water(tap water)
2. The filter effection will be some difference in different city water quality
3. If the pressure exceeds 0.3Mpa, please install the pressure limiting valve
4. This product requires professionals to operate.(installing and replace)
Features and Benefits
Broad chemical compatibility
Superior dirt-holding capacity
High flow rates and cost-effective
Quality
Cartridges produced in a controlled environment
Manufactured according to ISO9001 certified Quality Management System
Specification
| Materials of Construction | ||
| Filter Media | PP | |
| Support | PP | |
| Core, Cage and Drainage | PP | |
| End Caps | PP | |
| O-rings/Gasket | Viton/Silicone/EPDM/ TEV | |
| Sealing Technology | Thermal Bonding, No Adhesives | |
| Dimensions | ||
| Diameter | Φ68 | |
| Length | 5 inch, 10 inch, 20 inch, 30 inch, 40 inch | |
| Filtration Area, ft2 | ||
| ≥ 4.4 per 10-inch element | ||
| Pore Size, μm | ||
| 0.1, 0.22, 0.45, 0.65, 1.0, 3.0, 5.0, 10, 20 | ||
| Maximum Differential Pressure | ||
| Forward: 4.2 bar @ 23 ℃; 1.5 bar @ 85 ℃ | ||
| Flow Rate & Pressure Drop, per 10-inch cartridge | ||
| 0.1 μm | ≥ 18 L/min at 210 mba | |
| 0.22 μm | ≥ 25 L/min at 210 mbar | |
| 0.45 μm | ≥ 27 L/min at 210 mbar | |
Application:
>> Terminal filtration for solvent printing ink
>>Filtration for monomers of optical resin
>> Filtration for silicone oil
>> Final filtration for reagent-grade aggressive solutions
>> water filtration.
Product Picture:
A glance of our factory workshop
Company Picture
Our Company and Team :)
