Help CenterMetal Shell Fingerprint Reader With IR Remote Control, Biometric Fingerprint Reader
Related Products
-
Waterproof Metal Shell RFID Reader Support Connecting Any Card Readers With Wiegand Interface GAR-007EMNegotiableMOQ: 1 Piece -
Waterproof Metal Shell RFID Card Reader With Wiegand Interface and IR Remote Contrlol GAR-007EMUS$ 65 - 68MOQ: 1 Piece
-
RF Stailless Steel Fingerprint Scanner GAR-007EM With IR Remote ControlNegotiableMOQ: 1 Piece
-
RF Stailless Steel Biometric Fingerprint Scanner GAR-007EM With IR Remote ControlNegotiableMOQ: 1 Piece
-
RF Stailless Steel Biometric Fingerprint Reader GAR-007EM With IR Remote ControlNegotiableMOQ: 1 Piece
Specifications
Biometric Fingerprint Reader:1)Standalone fingerprint access control
2)stainless steel
3)Remote infrared programmer
1. Introduction
F007 use the precise electron circuit and good productive technology, which is the metal structure fingerprint & access machine.It is widely used in business affairs organization, office, factory, housing district etc.
This product’s programming is done by the infrared remote control keypad or fingerprint manager. This product maximum can store 120 fingerprints. There are 2 fingerprint managers, and each fingerprint has one ID code.
2. Specifications
Metal shell, anti-vandal.120 fingerprints
Remote infrared programmer
Lock release relay, NO and NC, 12 Volt DC SysteM
Fireproof, Shockproof Programmable lock release time
Sleep mode to save energy, built in PIR to wake up the device from sleep mod
Three color LED indicator Working temperature: -20°C-55°C
One second activation time, after placing finger on reader
Compact Size: 110mm*70m*30mm.N/W:500g, G/W:800G
Sleeping function
When this machine in stay status, it will auto enter sleep status. This can reduce power dissipation and prolong the machine’suse life.
Managerinfrared remote control keypad
Users use infrared remote control keypad, when enter the programming mode they can operate as follow:
Changing manager code,Add fingerprints,Delete fingerprints,Delete all fingerprints,release alarm,
Setting open door time,Setting release alarm
Manager fingerprint operation function
ID number 1: Manager add fingerprint (can’t open door, number 1 is used add users; number2 is used deleted users)
ID number 2: Manager delete fingerprint
ID number 3~120: users fingerprint
User fingerprint operation function
ID number 3~120: users fingerprint are used open door.
Open door button operation function
This button is used to open the door.
Parma setting function
Open door time: 0~10s, default setting 5s. User can use infrared remote control keypad setting.
Relay out
NC and COM: When power off , the lock is opened.
N0 and COM: When power on,the lock is opened.
Manager release alarm
When this machine is in stay status if it was opened, the buzzer will sound consecutive long ring. And it
will be kept for 1 minute.
Important information
If holes are to be drilled before mounting onto a wall, check for hidden cables and/or pipes before drilling. Use safety goggles when drilling or hammering in cable clips.
Every effort has been made to provide accurate information, however slight variations can occur. We also reserve the right to make changed for product improvement at any time.
