Specifications
CCD Grain/Cereal Color Sorter Machine1.accurately sorting any grains
2.high output
3.advanced technology
4.intelligent
CCD Grain/Cereal Color Sorter Machine
Product Introdution
1. Widely used in agriculture, industry, and other fields, for all kinds of grain crops, rice, industry of grain material which need to color choice .The quality and speed to make our products to be new and old customers .
2.Used advanced ccd camera technology on the color sorter to instead of the traditional electro-optical sensing technology to make the high sorting accuracy , performance ,effective and stable.
3. Inventively used the ccd true color sensor technology,2048 pixels,identify the area which less than 0.04mm² . For adopting high-powered DSP processor and FPGA chip, the system have powerful operation ability and powerful peripheral managing ability.
4. Special light source , we used the advanced light of lamp and LED with long life ,high light efficiency and high color rendering to improve the sorting accuracy to meet customers demands.Used advanced special slide ,reduce friction and convenient for maintenance.
5.Embedded operating system offers friendly interface ,easy to operate. convenient adjustment .
6.Reasonable heat output device, ensure all spare parts be working in the room temperature, SNR is better, not only increased the accuracy of sorting, but also extended the life of machine.
7. Professinal high frequency ejectors, save more air, reaction velocity is more quick, rate of accuracy is higher, and longer life, working with intelligent software, ensure the good rejection and excellent accuracy.
8. Simple optical system, precise auto calibration system and user-friendly man-machine interface greatly simplify the machine debugging process and ensure easy operation of our color sorter.
Technical Parameter
| Model | HNA2 | HNA3 | HNA4 | HNA5 |
| Output (t/h) | 1-3 | 2-6 | 3-8 | 4-9 |
| Sorting Accuracy (%) | ≥99.9 | ≥99.9 | ≥99.9 | ≥99.9 |
| Rejection Rate (Bad: Good ) | ≥5:1 | ≥5:1 | ≥5:1 | ≥5:1 |
| Weight | 680 | 830 | 1000 | 1120 |
| Minimum Resolution (mm2) | 0.04 | 0.04 | 0.04 | 0.04 |
| Power | 2.4(0.9) | 3.2(1.2) | 3.6(1.5) | 4.0(1.8) |
| Dimensions (L×W×H) mm | 1320×1490×2252 | 1660×1490×2252 | 2020×1500×2256 | 2360×1500×2256 |
| Voltage | 220v/50hz | 220v/50hz | 220v/50hz | 220v/50hz |
