Newly technology scrap copper wire cable granulator 0086 15333820631 Quality Choice

Specifications

Scrap Copper wire cable granulator
1. High capacity and efficiency
2. Easy operation
3. Cable diameter: 0.1-20mm,

Scrap Copper Wire Cable Granulator

I. Introduction of scrap copper wire cable granulator

Copper wire cable granulator mainly used for crusher and separate waste copper wire, the final material like the copperpellet.this kind of machine adopt newly technology, most of people say it is environmental protecton machine.

2. Classify and explain for scrap copper wire cable granulator

It can be divided into two parts:dry and wet copper wire cable granulator

Dry copper wire cable granulator means we are not need add water during separater, thiskind of machine mainly used for separate the  pneuatic separate/air table/electrostatic separation etc

Process of dry granulator: crusher-- pnueatic separate---(electrostatic separation: this kind of parts used little)--collect dust

Wet copper wire cable granulator is tradition methods, it mainly source mineral separation.It adopt gravity shake separation

Process of wet granulator: crusher and add water-- gravity shake separation (add water).When we are use this methods, it means that we are put the water into machine, it cause little pollution.But  it can recycle waste wire,plug cord etc.

3.Parameter of scrap copper wire cable granulator

Model	Capacity(kg/h)	Main power(kw)	Fan Power(kw)	Vibration power(kw)
LHO-TM400	300-400	30	3	0.75
LHO-TM600	400-500	37	3	0.75
LHO-TM800	700-800	45	4	0.75
LHO-TM1000	900-1000	55	5.5	0.75*2

first, just put the wire into it,crushed into samll pieces,then separated by separator and vibration,dust collector, finally, the pvc and copper will be got.generally, the purity can reach up to 99.5%.

Note:

1).pulverizer, elevator, separator, Dedusting system

2).Min diamerer of the wire is 0.1mm

3).dust collector system:  cyclone dust collector, pulsed jet cloth filter, Sponges filter dust

4).spare parts: screen, blades

5). Electrical Cabinets

4. Image of copper wire cable granulator
