Specifications
common rail test bench1.voltrage:220V/380V
2.test for injector and pump
3.power:15kw
4.test Denso HP0,HP3,HP4
HY-CRI200B-I common rail test bench
HY-CRI200B-1High Pressure Common Rail Injector Test Bench is the newly equipment to test common rail injector and common rail pump.It is controlled by industrial computer and WindowsXP.Fuel system is tested by sensors and displayed on LED screen.It can test common rail pump and injector produced by Bosch,Delphi,Denso and Siemens.
Name and Model |
System |
Configuration Details |
Remarks |
HY-CRI200B-I High Pressure Common Rail Injector Test Bench |
Main Engine System |
1. Tianqi quadrupole electric motor (380V): 15KW. Alpha frequency converter: 15KW 2. The main frame is cold box board and aviation aluminum composite structure, cast iron operating platform. 3. Its control type is automatically computer control and display by screen. 4. The accuracy of weighing oil digital readout (weighing transducer) is 0.1ml. 5. Its revolving speed range is 0~1500r/min (adjustable) (digital readout). 6. Height of main engine center is 125mm. |
Fixture Included |
Oil Circuit System |
1. Fuel delivery: 10L/min. 2. Fuel delivery pressure: 0~1Mpa. 3. Rail pipe is BOSCH. 4. Rail pressure: 0~200Mpa. 5. The rail pipe is controlled by automatically closed cycle, and pressure display (accuracy±0.1Mpa) with overpressure protection. 6. Oil temperature (adjustable) is controlled automatically, heated by heating pipe and refrigerated through strong refrigeration unit. |
||
Electrical equipment |
1. It has built-in electrical box and convert box. 2. Short-circuit protection. |
||
Data base |
It has more than 400 kinds of standard build-in data, which can be upgraded. |
||
Testing fuel injector and high pressure pump |
1. It can test 1 fuel injector every time. 2. It can test 6 fuel injectors at most in the same time (Price is extra). 3. The types it can test including BOSCH, DENSO, DELPHI, and SIEMENS. |
||
Overall dimension |
Length: 1600mm, Width: 800mm, Height: 1695mm |
||
Weight |
Net weigh: 1500kg. |
