0.3 FPC Connector

Specifications

29Pin FPC Connector 0.3mm Pitch ZIF SMT
1,RoHS,UL,CE
2,Insulator material: LCP(UL 94V-0)
3,Plating: gold plating

29Pin FPC Connector 0.3mm Pitch ZIF SMT



SPECIFICATIONS

  Current Rating:   0.5Amps
  Insulator Resistance:  500Megohms min

  Contact resistance:  20max.
  Dielectric Withstanding:   AC 500V
  Operating Temperature:   -20°c~+85°c

  Max processing temp: 230°c  for 30~60 seconds

                                          (260°c  for 10 seconds)

  Insulator material:  LCP  UL94V-0 RoHS

  Loeker material:  PPS UL94V-0 RoHS
  Contact Matericl:  Phosphor bronze

  Solder tab: Phosphor bronze
  Plating: gold plating
