Rubber Element for Coupling

Rubber Element for Coupling thumbnail-1
Rubber Element for Coupling photo-1
US$ 10 - 100 MOQ: 1 Set
Key Specifications
Get Latest Price
Structure:
Other, rubber
Flexible or Rigid:
Flexible
Standard or Nonstandard:
Standard
Contact Supplier Request Quote Chat Now
Cangzhou Tanso Coupling Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Structure Other, rubber
Flexible or Rigid Flexible
Standard or Nonstandard Standard
Material Other, rubber
Brand Name Tanso
Place of Origin Hebei, China
Model Number UL



Rubber element for couplingThis is tire coupling, UL coupling with rubber type element.

Type bolt-number Md*L allowable shaft hole main size     Length of shaft hole   allowable rotating speed moment of inertia weight(kg) slide torque
    D H D1 L (n kg.   Tn
  d                   dz       Y J1 Z1 r/min     N.m
UL1 12-M5*12 10  -- 18 80 20 29 22-42 5000 0.0003 0.7 10
UL2 12-M6*14 12 -- 22 100 26 36 27-52 5000 0.0008 1.2 25
UL3 12-M8*15 18 --  25 120 32 40 30-62 4800 0.0022 1.8 63
UL4 12-M8*18 20 -- 30 140 38 48 38-82 4500 0.0044 3 100
UL5 12-M10*20 24 -- 35 160 45 56 38-82 4000 0.0084 4.6 160
UL6 12-M10*22 25--40 180 50 65 44-112 3600 0.00164 7.1 250
UL7 12-M10*25 32 -- 48 200 56 78 60-112 3200 0.0029 10.9 315
UL8 12-M12*28 38 -- 50 220 63 80 60-112 3000 0.0045 13 400
UL9 16-M12*30 42 -- 60 250 71 100 84-142 2800 0.0089 20 630
UL10 16-M12*35 45 --70 280 80 120 84-142 2400 0.0159 30.6 800
UL11 16-M16*40 50 -- 75 320 90 125 84-142 2100 0.0279 39 1000
UL12 12-M16*45 55 -- 85 360 100 150 84-172 2000 0.535 59 1600
UL13 16-M16*50 63 --95 400 110 170 107-172 1800 0.896 81 2500
UL14 24-M20*60 75 -- 110 480 130 210 107-212 1600 2.261 145 4000
UL15 24-M20*68 85 --125 560 150 255 132-212 1200 4.645 222 6300
UL16 16-M24*68 100 -- 140 630 180 280 167-252 1000 8.092 302 10000
UL17 24-M24*76 120 -- 160 750 210 350 167-302 900 20.017 561 16000
UL18 24-M30*86 140 --180 900 250 420 202-302 800 43.053 818 25000
