Wou-xun Brand LT-UV6D DTMF 1750HZ Tone Dual Band Two Way Radio

Wou-xun Brand LT-UV6D DTMF 1750HZ Tone Dual Band Two Way Radio thumbnail-1
Wou-xun Brand LT-UV6D DTMF 1750HZ Tone Dual Band Two Way Radio photo-1
US$ 55 - 60 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Wou-xun dual band radio
Model Number:
LT-UV6D 2 way radio
Contact Supplier Request Quote Chat Now
Quanzhou Bond Telecom Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Wou-xun dual band radio
Model Number LT-UV6D 2 way radio
Type Handheld
Dimensions 58*105*38MM
Frequency Range 136-174/400-470/450-520MHz
Storage Channel 128 Channels
Talk Range 5-7KM

Specifications

Wou-xun dual band two way radio
DTMF/1750 TONE
Warranty: 1 year
Delivery time: 3days after T/T

Wou-xun brand LT-UV6D DTMF 1750HZ Tone dual band two way radio



Wou-xun dual band radio/ dual band two way radio/ dual band walkie talkie/ dual band transaceiver





Wou-xun brand LT-UV6D DTMF 1750HZ Tone dual band two way radio

LT-UV6D Specification



CE/FCC approval.

Frequency Range can be suitable for different countries or areas

136-174/400-470MHz (RX/TX)

136-174/450-520MHz (TX/TX)

66-88/400-470MHz (TX/TX)

FM: 76-108MHz (RX)

Work Mode: U-V/V-U/V-V/U-U can be set freely

SOS Function

1750Hz tone

DTMF Encoding Function

CTCSS/DCS Scan (Digital/Analog)

Bright Flashlight Illumination

Ban can be set freely on the same channel VHF TX-UHF RX or UHF T-VHF RX

English voice guide

Digital FM Radio

Wide/Narrow bandwidth selection (25KHz / 12.5KHz)

Priority scan, Add scanning channel

High/Low power selection

Channel Name Edit and display

50 groups CTCSS/105 groups DCS

Multi step frequency: (5K/6.25K/10K/25K/50K/100K)

Multi scan

VOX transmission

Transmit overtime voice prompt

Begin/End transmitting BEEP prompt

Auto/Manual keypad lock

Wire clone, programmable by computer

Stopwatch function

Low voltage VOICE prompt

Busy channel lockout

Wou-xun brand LT-UV6D DTMF 1750HZ Tone dual band two way radio

Technical Specification

LT-UV6D technical specification











Frequency range

Frequency range can be suitable for different countries or areas:

136-174/400-470MHz (RX/TX)

136-174/450-520MHz (TX/TX)

66-88/400-470MHz (TX/TX)

FM: 76-108MHz (RX)



Memory Channels

128 Channels

Frequency Stability

±2.5ppm

Operating Temperature

-30°C≈+60°C

Waterproof

IP55

Antenna Impedance

50

Dimension

58*105*38mm

Weight

250g

Transmitter

Frequency stability

±2.5ppm

RF Carrier Power

Within pre-determined value±7.5dB

Max. Frequency Deviation

Channel space: 25KHz ±5KHz

Channel space: 12.5KHz ±2.5KHz

Audio Modulation

+3dB(pre-emphasis by 6dB between 0.3-3KHz)

Adjacent channel power

Channel space: 25KHz≥70dB

Channel space: 12.5KHz≥60dB

Spurious Radiation

≤30dBm

Inter modulation Attenuation

≥40dB

Modulation Distortion

≤10%

Residual FM

≤-35dB

Residual FM

≤3%

Receiver

Sensitivity(12dB SINAD)

0.16μV

Squelch rejection Sensitivity

≤0.8μV

Squelch Sensitivity

≤0.2μV

Audio output power

500mW

Audio Distortion

≤5%

Audio Response

(300-3000Hz)+1 to -3dB

Co-channel Rejection

≥-8.0dB

Performance of Amplitude Limited

≤3

Adjacent Channel Selection

Channel space: 25KHz≥70dB

Channel space: 12.5KHz≥60dB

Inter-modulation

≥65dB

Resistance

≥84dB

Spurious Radiation

9Khz-1GHz≤-57dBm

1GHz-4GHz≤-47dBm

Wou-xun brand LT-UV6D DTMF 1750HZ Tone dual band two way radio

1pc radio body

1pc battery

1pc antenna

1pc charger+adpater

1pc belt+strap

1pc manual

1pc manual
