Wou-xun Brand LT-UV6D Dual Band Handheld fm Transmitter

Quanzhou Bond Telecom Co., Ltd.
Wou-xun Brand LT-UV6D Dual Band Handheld fm Transmitter thumbnail-1
Wou-xun Brand LT-UV6D Dual Band Handheld fm Transmitter photo-1
US$ 55 - 58 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Wou-xun dual band radio
Model Number:
LT-UV6D 2 way radio
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Wou-xun dual band radio
Model Number LT-UV6D 2 way radio
Type Handheld
Dimensions 58*105*38MM
Frequency Range 136-174/400-470/450-520MHz
Storage Channel 128 Channels
Talk Range 5-7KM

Specifications

Wou-xun dual band ham radio
DTMF/1750 TONE
Warranty: 1 year
Delivery time: 3days after T/T

 LT-UV6D Specification

1, CE/FCC approval.

2, Frequency Range can be suitable for different countries or areas

136-174/400-470MHz (RX/TX)

136-174/450-520MHz (TX/TX)

3, FM: 76-108MHz (RX)

4, Work Mode: U-V/V-U/V-V/U-U can be set freely

5, SOS Function

6, 1750Hz tone

7, DTMF Encoding Function

8, CTCSS/DCS Scan (Digital/Analog)

9, Bright Flashlight Illumination

10, Ban can be set freely on the same channel VHF TX-UHF RX or UHF T-VHF RX

11, English voice guide

12, Digital FM Radio

13, Wide/Narrow bandwidth selection (25KHz / 12.5KHz)

14, Priority scan, Add scanning channel

15, High/Low power selection

16, Channel Name Edit and display

17, 50 groups CTCSS/105 groups DCS

18, Multi step frequency: (5K/6.25K/10K/25K/50K/100K)

19, ,Multi scan

20, ,VOX transmission

21, Transmit overtime voice prompt

22, Begin/End transmitting BEEP prompt

23, Auto/Manual keypad lock

24, Wire clone, programmable by computer

25, Stopwatch function

26, Low voltage VOICE prompt

27, Busy channel lockout



Technical Specification

LT-UV6D technical specification

Frequency range

136-174/400-470MHz (RX/TX)

136-174/450-520MHz (TX/TX)

FM: 76-108MHz (RX)

Memory Channels

128 Channels

Frequency Stability

±2.5ppm

Operating Temperature

-30°C≈+60°C

Waterproof

IP55

Antenna Impedance

50

Dimension

58*105*38mm

Weight

250g

Transmitter

Frequency stability

±2.5ppm

RF Carrier Power

Within pre-determined value±7.5dB

Max. Frequency Deviation

Channel space: 25KHz ±5KHz

Channel space: 12.5KHz ±2.5KHz

Audio Modulation

+3dB(pre-emphasis by 6dB between 0.3-3KHz)

Adjacent channel power

Channel space: 25KHz≥70dB

Channel space: 12.5KHz≥60dB

Spurious Radiation

≤30dBm

Inter modulation Attenuation

≥40dB

Modulation Distortion

≤10%

Residual FM

≤-35dB

Residual FM

≤3%

Receiver

Sensitivity(12dB SINAD)

0.16μV

Squelch rejection Sensitivity

≤0.8μV

Squelch Sensitivity

≤0.2μV

Audio output power

500mW

Audio Distortion

≤5%

Audio Response

(300-3000Hz)+1 to -3dB

Co-channel Rejection

≥-8.0dB

Performance of Amplitude Limited

≤3

Adjacent Channel Selection

Channel space: 25KHz≥70dB

Channel space: 12.5KHz≥60dB

Inter-modulation

≥65dB

Resistance

≥84dB

Spurious Radiation

9Khz-1GHz≤-57dBm

1GHz-4GHz≤-47dBm



Wou-xun brand LT-UV6D dual band handheld fm transmitter
