Packaging & Delivery
| Packaging Details: | screw barrel 1. Be brushed anti-corrosive oil on screw barrel. 2. Packed with film. 3. Packed in the wooden. |
| Delivery Detail: | 10-30days for screw barrel |
We can do any kind of screw barrel for extruder molding machine, injection molding machine and blow molding machine, see the plastic products application as below.
THE PLASTIC SCRAP:
First stage:
Motor: 55kw-4P, Brand: Weinuo, from Nanjing city.
Control method: by inverter, brand: Pioneer from Shanghai city.
250# Gearbox: Hard-Tooth Surface, brand: Shuguang, from Xiaoshan city
Screw barrel material: 38CrAlA.
Screw Dia.: 140mm; Barrel Dia.:190mm
L/D ratio: 22:1
Screw length: 3000mm
Barrel heater: Ceramic heater
Hydraulic controlled screen changer
Sieve dia.: 250mm
Material Hopper: designed with compulsory feeder to push the crushed scraps into screw barrel more faster.
Feeder motor: 1.5KW-6P with inverter control
Second stage:
Motor: 18.5kw-4P, Brand: Weinuo, from Nanjing city.
Control method: by inverter, brand: Pioneer from Shanghai city.
180# Gearbox: Hard-Tooth Surface, brand: Shuguang, from Xiaoshan city
Screw barrel material: 38CrAlA.
Screw Dia.: 117mm; Barrel Dia.:160mm
L/D ratio: 10:1
Screw length: 1200mm
Barrel heater: Stainless steel heater
Hydraulic controlled screen changer
Sieve dia.: 220mm
Water tank: made by thick steel, 2500×500×300MM
Air blowing dryer: 1 set
Fan motor power: 1.5KW
Rotary Normal Speed Cutter: 1set
Adjustable Speed Motor: 3KW,
Electrical Control cabinet: 1 set
Circuit breakers: Schneider
