110kw Lovol Water Power Used Diesel Generators With CE Approved

110kw Lovol Water Power Used Diesel Generators With CE Approved thumbnail-1
110kw Lovol Water Power Used Diesel Generators With CE Approved photo-1
US$ 3,000 - 120,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Lovol
Model Number:
DSL
Contact Supplier Request Quote Chat Now
Xiamen Huadong Machine Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Lovol
Model Number DSL
Output Type AC Three Phase
Speed 1500/1800rpm
Frequency 50/60hz
Rated Power 110kw/138kva
Rated Voltage 220/380v 240/415v
Rated Current 198A

Specifications

110kw used diesel generators with CE
High quality with best price
Environment-friendly
Low noise 1006TAG

 110kw lovol water power used diesel generators with CE approved



Engine model: 1003G, 1003TG, 1004G, 1004TG, 1006TG1A, 1006TG2A, 1006TAG1A, 1006TAG



Performance Feature
- Engine and alternator shall be mounted on a same frame steel skid.
- Built-in damper for anti-vibration.
- Small size, low weight, easy to operating, installation and maintenance.
- World most famous brand diesel engine.
- World famous brand AC alternator: Stamford, Marathon, Leroy Somer, MVC.
- Advanced and reliable control module: Key start, Auto start, Remote control by PC with RS232/485
- Full range protect function and alarm shutdown feature.

Protection Standard: IP21-IP23
Model of connection: 3 phase 4 lines
Insulation Grade: H
Frequency Drop(%): ≤ 0.5
Transient state frequency deviation(%): (advertised power) +10-7
Frequency Recovery Time(S): ≤ 3
Voltage Recovery Time(S): ≤ 4
Waveform Distortion(%): ≤ 5



Alternator for option

Brand Model
Engga EG225L-120N
Stamford UCI274F
Leroy-somer LSA47.2 M7
Marathon MP-120-4



Alternator Feature
- Brush-less, 4 poles, rotation magnet.
- IP21-23(NEMA1) enclosure is standard for all industrial alternators.
- The insulation system is Class H
- Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts.
- Wide range of flange adaptors and single bearing disc coupling.
- Standard 2/3 pitch windings avoid excessive neutral currents
- AVR auto voltage regulator, auto exciter, auto adjustment



Standard Accessory
Common steel base frame, Circuit breaker, Damper, Exhaust silencer, Flexible pipe, Battery and connecting wires, Operation manual and document.



Optional Accessory

Engine coolant and oil heater, Alternator space heater, Cooling for heat exchanger, Control system with RS232/485 communication interface, Battery charger by main supply, Fuel-water separator, Daily fuel tank, ATS & paralleling system, Soundproof Canopy and Moving Trailer.



Lovol generator 20kw to 110kw data

Genset model Prime power Standby power Engine model Fuel consumption (g/kwh) Cylinder Displacement(L) Bore*stroke(mm) Weight(kg)) Dimension(mm)
KW KVA KW KVA
DSL20 20 25 22 28 1003G 210 3L 5.9 100×127 700 1900×850×1150
DSL30 30 38 33 41 1003TG 205 3L 3.99 100×127 720 1900×850×1150
DSL34 34 43 37 46 1003TG 205 3L 3.99 100×127 780 1900×850×1150
DSL30 30 38 33 41 1004G 210 4L 3.99 100×127 1000 1950×850×1150
DSL34 34 43 37 46 1004G 210 4L 3.99 100×127 1000 1950×850×1150
DSL48 48 60 53 66 1004TG 205 4L 3.99 100×127 1030 2000×900×1180
DSL58 58 73 64 80 1004TG 205 4L 3.99 100×127 1060 2000×900×1180
DSL68 68 85 75 94 1006TG1A 205 6L 5.9 100×127 1100 2300×950×1350
DSL75 75 94 83 104 1006TG1A 205 6L 5.9 100×127 1310 2300×950×1350
DSL80 80 100 88 110 1006TG2A 205 6L 5.9 100×127 1330 2300×950×1350
DSL86 86 108 95 119 1006TAG1A 205 6L 5.9 100×127 1360 2300×950×1350
DSL90 90 113 99 124 1006TAG1A 205 6L 5.9 100×127 1400 2400×950×1400
DSL96 96 120 106 133 1006TAG1A 205 6L 5.9 100×127 1420 2400×950×1400
DSL110 110 138 121 151 1006TAG 205 6L 5.9 100×127 1440 2400×950×1400



Controller

110kw lovol water power used diesel generators with CE approved



Factory

110kw lovol water power used diesel generators with CE approved
