Doosan Engine Diesel Generator for Sale

Doosan Engine Diesel Generator for Sale thumbnail-1
Doosan Engine Diesel Generator for Sale photo-1
US$ 3,000 - 40,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Doosan daewoo
Model Number:
DSD
Contact Supplier Request Quote Chat Now
Xiamen Huadong Machine Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Doosan daewoo
Model Number DSD
Output Type AC Three Phase
Speed 1500rpm/1800rpm
Frequency 50hz/60hz
Rated Power 48kw to 560kw
Rated Voltage 220v/400v
Rated Current 86A-1008A

Specifications

Doosan engine diesel generator for sale
24v dc motor
Daewoo generator with OEM price
1 year or 1000 working hours global

Original doosan engine diesel generator for sale



Introduction:

Doosan Engine started out in 1984 with an annual capacity of 200,000 bhp (150,000 kW) in large diesel engines for ships and power plants. Annual output now stands at 14 million bhp, and the company’s share of the world market has reached 25 percent. Doosan Engine achieved 50 million bhp in aggregate production after just twenty years, an industry record, and has built the world’s largest electronically controlled marine engine. The company's business today is mainly building and maintaining low and medium speed marine engines ranging from 60kva to 700kva.



Diesel engine:doosan engine
1. Multi-cylinder in-line or veer engine. 4-stroke, direct injection
2. Governer Method:electrical or mechanical governor
3.  Water cooling
4. Intake method:Natural apirated or turbocharged
5. Electric motor starting system



Alternator: Stanford, LeroySomer, Marathon, Engga
a) Brushless, 4 poles, rotation magnet
b) IP21-23(NEMA1) enclose is standard for all industrial alternators
c) H class insulation system
d) AVR self-regulated, voltage regulation rate: ≤±1%
e) Wide range of flange adaptors and single bearing disc coupling
f) Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528
g) Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof

Control plane:
a) Automatic alarm system: the unit has the acoustic-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature the oil pulls down, over speed, over load and over current
b) Operation display:
  i) Unit voltage, tri-phase load current and frequency display
  ii) Water temperature, oil pressure display
  iii) Fuel level, fuel temperature dieplay
  iv) Audible and visual alarm lamps and buzzers

c) Emergency stop button
d) Three protection



Doosan Daewoo diesel generator data parameter

Genset model Prime power Standby power Engine model At full load consumption cylinder Displacement(L) Bore*stroke(mm) Weight(Kg) Dimension(mm)
KW KVA KW KVA
DSD60 48 60 53 66 DB58 213 6L 5.785 102×110 820 2050×800×1000
DSD88 70 88 77 96 D1146 222 6L 8.071 111×139 1050 2200×800×1550
DSD125 100 125 110 138 D1146T 200 6L 8.071 111×139 1160 2350×800×1250
DSD169 135 169 149 186 P086TI-1 202 6L 8.071 111×139 1750 2600×950×1450
DSD200 160 200 176 220 P086TI 202 6L 8.071 111×139 1750 2600×1000×1500
DSD275 220 275 242 303 P126TI 200 6L 11.05 123×155 1950 3000×1100×1500
DSD313 250 313 275 344 P126TI-II 202 6L 11.05 126×155 2100 3000×1100×1500
DSD375 300 375 330 413 P158LE-1 202 8V 14.62 128×142 2400 3000×1400×1900
DSD400 320 400 352 440 P158LE 202 8V 14.62 128×142 2550 3000×1400×1900
DSD450 360 450 396 495 P158LE-S 209 8V 14.62 128×142 2750 3200×1400×1900
DSD450 360 450 396 495 P158FE 203 8V 14.62 128×142 3000 3300×1400×1900
DSD450 360 450 396 495 P180LE-1 205 10V 18.27 128×142 3000 3300×1400×1900
DSD500 400 500 440 550 P180LE 205 10V 18.27 128×142 3000 3300×1400×1900
DSD500 400 500 440 550 P180LE-S 205 10V 18.27 128×142 3000 3300×1400×1900
DSD500 400 500 440 550 P180FE 205 10V 18.27 128×142 3200 3200×1400×1900
DSD575 460 575 506 633 P222LE-1 209 12V 21.93 128×142 3550 3300×1400×1900
DSD625 500 625 550 688 P222LE 209 12V 21.93 128×142 3600 3300×1400×1900
DSD625 500 625 550 688 P222LE-S 202 12V 21.93 128×142 3800 3400×1400×1900
DSD650 520 650 572 715 P222FE 200 12V 21.93 128×142 3800 3400×1400×1900
DSD700 560 700 616 770 P222LE-II 200 12V 21.93 128×142 4000 3300×1400×1900





Doosan engine diesel generator for sale

Doosan engine diesel generator for sale

Doosan engine diesel generator for sale

Doosan engine diesel generator for sale
