Help CenterChinese Famous 5t 162kw 3.0m3 Wheel Loaders
Related Products
1. Specification for wheel loader 5tons LG855B
a. Lonking brand (longgong) belong to the first grade level brand in China
(Hight quality )
b. Lonking the transimission and engine used the own longking produced.
c. The LG855B the singel arm to operation ( Big force, and the quick effective work)
d. The weichai engine which using the German technologe cooperation,which much popular in Chinese most of customers .
Overall Data 5ton wheel loader LG855B | ||||||||||||
Bucket Capacity (m3) |
3.0 |
|||||||||||
Rated Payload(kg) |
5000 |
|||||||||||
Operating Weight (kg) |
16600±300 |
|||||||||||
Traction Force(kN) |
150±3 |
|||||||||||
Breakout Force (kN) |
170±3 |
|||||||||||
Travel speeds (km/h): | ||||||||||||
|
I |
II |
|
|||||||||
Forward |
11.5 |
36.0 |
|
|||||||||
Reverse |
16.0 |
|
|
|||||||||
Engine |
WEICHAI WD10G220E21 |
|||||||||||
Rated Power(kw/rpm) |
162/2200 |
|||||||||||
Peak Torque(Nm/rpm) |
850/1400-1600 |
|||||||||||
Starting Voltage(V) |
24 |
|||||||||||
Drive Train | ||||||||||||
Torque Converte |
Single-stage, Duo-turbine, 4-element |
|||||||||||
Torque Ratio |
4.0 |
|||||||||||
Transmission |
Planetary Powershift Transmission |
|||||||||||
Gear |
2F/1R |
|||||||||||
Pressure of Transmission (MPa) |
1.2-1.5 |
|||||||||||
Main Reducer |
Spiral Bevel, 1-stage Reduction |
|||||||||||
Final Reducer |
Planetary Reduction |
|||||||||||
Tire |
23.5-25 L-3 16PR |
|||||||||||
Brake System | ||||||||||||
Service Brake |
Single Circuit Caliper,Dry Brake |
|||||||||||
Setting Pressure (MPa) |
0.78 |
|||||||||||
Parking Brake |
Air Actuated Caliper Brake |
|||||||||||
Steering System | ||||||||||||
Type |
Hydraulic Load Sensor System |
|||||||||||
Cylinders-bore×Stroke (mm) |
2-100×324 |
|||||||||||
Steering Pump |
Gear Pump |
|||||||||||
System Pressure (MPa) |
16 |
|||||||||||
Flow Rate (L/min/RPM) |
176/2200 |
|||||||||||
Steering Angle |
±35° |
|||||||||||
Hydraulic System | ||||||||||||
Lift Cylinders-bore×Stroke (mm) |
2-180×721 |
|||||||||||
Tilt Cylinder-bore×Stroke (mm) |
1-200×563 |
|||||||||||
Model of Working Pump |
|
|||||||||||
Flow Rate (L/min/RPM) |
220/2200 |
|||||||||||
System Pressure (MPa) |
16 |
|||||||||||
|
|
|||||||||||
Hydraulic cycle time, rated load in bucket(in second): | ||||||||||||
Raise(Loaded) |
Dump |
Lower(Empty) |
Total |
|||||||||
6.0 |
1.2 |
4.3 |
11.5 |
|||||||||
Electrical System | ||||||||||||
System Voltage(V) |
24 |
|||||||||||
Battery (2 in series)(Ah) |
120 |
|||||||||||
Lamp Voltage (V) |
24 |
|||||||||||
Service Refill Capacity | ||||||||||||
Fuel Tank (L) |
285 |
|||||||||||
Hydraulic Tank (L) |
285 |
|||||||||||
Crankshaft (L) |
20 |
|||||||||||
Transmission(L) |
45 |
|||||||||||
Front Axle(L) /Rear Axle(L) |
23/23 |
|||||||||||
2. Package and Shipment:
By nude on buld shipment , roll on shipment or 40HQ (separate the wheel loader on 40HQ)
