Help Center5T Fork Wheel Loaders in the Wood Catching Working Situation
Related Products
-
3T Wheel Loaders With Tautzin Guangzhou CityNegotiableMOQ: 1 Unit -
3T Side Dump Wheel Loaders Working in the Tunnal Work SituationNegotiableMOQ: 1 Unit
-
5T Side Dump Wheel Loaders Working in the Tunnal Work SituationNegotiableMOQ: 1 Unit
-
Chinese Famous 5t 162kw 3.0m3 Wheel LoadersNegotiableMOQ: 1 Unit
-
6ton Lonking Big Wheel LoaderNegotiableMOQ: 1 Piece
Specifications
1.5ton wheel loader2. Engine: Weichai 162kw
3. Fork mix, open:508mm
4. Fork Max.open:2013mm
5. Fork width :2064mm
1. Specification for wheel loader 5tons LG855BJ ( J means Fork)
1.1Fork mix, open:508mm
1.2 Fork Max.open:2013mm
1.3 Fork width :2064mm
a. Lonking brand (longgong) belong to the first grade level brand in China
(Hight quality )
b. Lonking the transimission and engine used the own longking produced.
c. The LG855B the singel arm to operation ( Big force, and the quick effective work)
d. The weichai engine which using the German technologe cooperation,which much popular in Chinese most of customers .
Overall Data 5ton wheel loader LG855B | ||||||||||||
Bucket Capacity (m3) |
3.0 |
|||||||||||
Rated Payload(kg) |
5000 |
|||||||||||
Operating Weight (kg) |
16600±300 |
|||||||||||
Traction Force(kN) |
150±3 |
|||||||||||
Breakout Force (kN) |
170±3 |
|||||||||||
Travel speeds (km/h): | ||||||||||||
|
I |
II |
|
|||||||||
Forward |
11.5 |
36.0 |
|
|||||||||
Reverse |
16.0 |
|
|
|||||||||
Engine |
WEICHAI WD10G220E21 |
|||||||||||
Rated Power(kw/rpm) |
162/2200 |
|||||||||||
Peak Torque(Nm/rpm) |
850/1400-1600 |
|||||||||||
Starting Voltage(V) |
24 |
|||||||||||
Drive Train | ||||||||||||
Torque Converte |
Single-stage, Duo-turbine, 4-element |
|||||||||||
Torque Ratio |
4.0 |
|||||||||||
Transmission |
Planetary Powershift Transmission |
|||||||||||
Gear |
2F/1R |
|||||||||||
Pressure of Transmission (MPa) |
1.2-1.5 |
|||||||||||
Main Reducer |
Spiral Bevel, 1-stage Reduction |
|||||||||||
Final Reducer |
Planetary Reduction |
|||||||||||
Tire |
23.5-25 L-3 16PR |
|||||||||||
Brake System | ||||||||||||
Service Brake |
Single Circuit Caliper,Dry Brake |
|||||||||||
Setting Pressure (MPa) |
0.78 |
|||||||||||
Parking Brake |
Air Actuated Caliper Brake |
|||||||||||
Steering System | ||||||||||||
Type |
Hydraulic Load Sensor System |
|||||||||||
Cylinders-bore×Stroke (mm) |
2-100×324 |
|||||||||||
Steering Pump |
Gear Pump |
|||||||||||
System Pressure (MPa) |
16 |
|||||||||||
Flow Rate (L/min/RPM) |
176/2200 |
|||||||||||
Steering Angle |
±35° |
|||||||||||
Hydraulic System | ||||||||||||
Lift Cylinders-bore×Stroke (mm) |
2-180×721 |
|||||||||||
Tilt Cylinder-bore×Stroke (mm) |
1-200×563 |
|||||||||||
Model of Working Pump |
|
|||||||||||
Flow Rate (L/min/RPM) |
220/2200 |
|||||||||||
System Pressure (MPa) |
16 |
|||||||||||
|
|
|||||||||||
Hydraulic cycle time, rated load in bucket(in second): | ||||||||||||
Raise(Loaded) |
Dump |
Lower(Empty) |
Total |
|||||||||
6.0 |
1.2 |
4.3 |
11.5 |
|||||||||
Electrical System | ||||||||||||
System Voltage(V) |
24 |
|||||||||||
Battery (2 in series)(Ah) |
120 |
|||||||||||
Lamp Voltage (V) |
24 |
|||||||||||
Service Refill Capacity | ||||||||||||
Fuel Tank (L) |
285 |
|||||||||||
Hydraulic Tank (L) |
285 |
|||||||||||
Crankshaft (L) |
20 |
|||||||||||
Transmission(L) |
45 |
|||||||||||
Front Axle(L) /Rear Axle(L) |
23/23 |
|||||||||||
2. Package and Shipment:
By nude on buld shipment , roll on shipment or 40HQ (separate the wheel loader on 40HQ)
