Help Center3T New Wheel Loader With Bucket Capacity 1.8m3
Related Products
-
938 Wheel Loader New Machine 3t With 1.8m3US$ 24,000 - 26,000MOQ: 1 Unit -
5T Fork Wheel Loaders Catching the Grass for SaleNegotiableMOQ: 1 Unit
-
Longgong3.0m3 Wheel LoadersNegotiableMOQ: 1 Unit
-
5T Fork Wheel Loaders for Sale With Wood Clipper,log LoaderNegotiableMOQ: 1 Unit
-
5T Fork Wheel Loaders in the Wood Catching Working SituationNegotiableMOQ: 1 Unit
Lonking wheel loader 3T bucket capacity is 1.8m3 Model is LG833BG
Famous EngineAutomatic LevelingConvenient Maintenance Centering Arranged Long Wheelbase
Detachable Cab
RATED POWER: 92kW/2200rpm
BUCKET CAPACITY: 1.8m3
RATED PAYLOAD: 3000kg
OPERATING WEIGHT: 10760kg
Our company : Trust company AAAA
Our warehouse :
Specification for Lonking Brand Wheel loader 3T LG833BG (Long Arm)
Overall Data |
LG833BG |
|||||||||||||||
Bucket Capacity (m3) |
1.8 |
|||||||||||||||
Rated Payload (Kg) |
3000 |
|||||||||||||||
Operating Weight(Kg) |
10760±300 |
|||||||||||||||
Traction Force (kN) |
97±3 |
|||||||||||||||
Breakout Force (kN) |
100±3 |
|||||||||||||||
Travel speeds (km/h): | ||||||||||||||||
|
I |
II |
III |
|
||||||||||||
Forward |
6.5 |
12.0 |
32.0 |
|
||||||||||||
Reverse |
6.8 |
12.5 |
33.5 |
|
||||||||||||
Engine |
TD226B-61G15 |
|||||||||||||||
Rated Power (kW/rpm) |
92/2200 |
|||||||||||||||
Peak Torque (Nm/rpm) |
500/1400-1600 |
|||||||||||||||
Starting Voltage(V) |
24 |
|||||||||||||||
Drive Train |
|
|||||||||||||||
Torque Converter |
Single-stage, Single-turbine, 3-element |
|||||||||||||||
Torque Ratio |
3.5 |
|||||||||||||||
Transmission |
Counter shaft Power shift Transmission |
|||||||||||||||
Gear |
3F/3R |
|||||||||||||||
Pressure of Transmission (MPa) |
1.2~1.5 |
|||||||||||||||
Main Reducer |
Spiral bevel, 1-stage Reduction |
|||||||||||||||
Final Reducer |
Planetary Reduction |
|||||||||||||||
Tire |
17.5-25 L-3 12PR TT |
|||||||||||||||
Brake System |
|
|||||||||||||||
Service Brake |
Single Circuit Caliper ,Dry Brake |
|||||||||||||||
Setting Pressure (MPa) |
0.78 |
|||||||||||||||
Parking Brake |
Flexible Shaft Controlled Caliper |
|||||||||||||||
Emergency Brake |
Flexible Shaft Controlled Caliper |
|||||||||||||||
Steering System |
|
|||||||||||||||
Type |
Hydraulic Load Sensing System |
|||||||||||||||
Cylinders-bore× Stroke (mm) |
2-80×315 |
|||||||||||||||
Steering Pump |
Gear Pump |
|||||||||||||||
System Pressure (MPa) |
14 |
|||||||||||||||
Flow rate(L/min/rpm) |
88/2200 |
|||||||||||||||
Steering Angle |
±35° |
|||||||||||||||
Hydraulic System |
|
|||||||||||||||
Lift Cylinders-bore× Stroke(mm) |
2-125×784 |
|||||||||||||||
Tilt Cylinder-bore× Stroke(mm) |
1-140×553 |
|||||||||||||||
Model of Implement Pump |
Gear Pump |
|||||||||||||||
Flow rate(L/min/rpm) |
176/2200 |
|||||||||||||||
System Pressure (MPa) |
16 |
|||||||||||||||
Pilot Control System Pressure (MPa) |
2.5 |
|||||||||||||||
Hydraulic Cycle Time, Rated Load in Bucket (in second): | ||||||||||||||||
Raise(Loaded) |
Dump |
Lower(Empty) |
Total |
|||||||||||||
5.5 |
1.3 |
3.7 |
10.5 |
|||||||||||||
Electrical System | ||||||||||||||||
System Voltage(V) |
24 |
|||||||||||||||
Battery (2 in series)(Ah) |
105 |
|||||||||||||||
Lamp Voltage(V) |
24 |
|||||||||||||||
Service Refill Capacity |
|
|||||||||||||||
Fuel Tank(L) |
200 |
|||||||||||||||
Hydraulic Tank(L) |
173 |
|||||||||||||||
Crankshaft(L) |
17 |
|||||||||||||||
Transmission(L) |
36 |
|||||||||||||||
Front Axle(L) /Rear Axle(L) |
18.5/18.5 |
|||||||||||||||
