LGX-Z410C-1 Hydraulic DTH Rig
Application
The main application of LGX-Z410C-1 hydraulic DTH rig is blast hole drilling in mining or construction of road, railway and water power station. In domestic China, It is the only separate rig that need only single operator. The wise layout of diesel engine, excavator chassis and dust colleting devices results an excellent environmental and cost saving performance.
Specifications (Main Parameters)
Working Pressure |
0.7-1.5 Mpa |
Exhaust Capacity |
7-13 m3/min |
Hole Range |
83-115 mm |
Hammers Option |
90A,930,90 high pressure |
Hole Depth Max. |
20 m |
Rod Length |
2000 mm |
Drill Steel Diameter |
60 mm |
Slope Ability Max. |
30° |
Tramming Speed |
1.8-3 km/h |
Rotation Speed |
0-100 rpm |
Torque Max. |
1200 Nm |
Total Weight |
Total Weight |
Profile Dimension |
4650×1900×2600 (mm3) |
Power Pack |
yuchai 4D80 engine |
Dust Collector |
EURO II |
Heavy Duty Tramming Motor |
EURO II |
Advantage
Features & Benefit
1.New type of cycloid motor for rotator provides powerful torque that reduces jamming.
2.The rotation can be regulated as per different rock condition that achieves successful penetration.
3.Double drill steel storage benefit sole operator to long extension drilling.
4. Designed and developed by Legos, the high performance moist air filter together with dry filter formed 3 stages filtering which is better for diesel engine.
5.High efficiency dry dust collector.
6.Heavy duty motor for tramming.
Product Display
