SC-02 LCD Display 30A Solar Controller (12V/24V Auto Detect)

SC-02 LCD Display 30A Solar Controller (12V/24V Auto Detect) photo-1
US$ 65 - 70 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Brand Name:
NSmart/OEM
Model Number:
SC-02
Use:
Other, Solar System Controller
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name NSmart/OEM
Model Number SC-02
Use Other, Solar System Controller
Type Solar
Place of Origin Guangdong, China

Specifications

1.30A solar controller
2.12v/24V identify automatically
3.PWM function supported
4.12 month warranty

SC-02  LCD display 30A solar controller (12V/24V auto detect)





  Specification



Products specification



1

      Model       YH-SC1230

2

      Name      30A  solar controller

3

      Rated voltage      12V/24V automatic identification

4

      Strong charging pressure      14.8V/29.6V

5

      Balanced filling      14.5V/29V

6

      Float chargering pressure      13.7V/27.4V(25°C)

7

      Low pressure load off voltage      11v/22v±0.2

8

      Load connect voltage      12.5V/25.5V

9

      Temperature compensation system      -4mV/C/2V

10

      Maximum charger current      30A

11

      Maximum load current      30A

12

      Maximum cable diameter      8mm²

13

      Weight(gross)/set      600g

14

      Working temperature      -40-60°C

15

      Protection grade      IP56             Advantage

1

      LCD display, automatic temperature compensation

2

      Battery protection, avoid solar battery overcharger,battery reverse-discharger protection



3

      Adapter MCU contol, five charging and discharging LED indicator, capacity state      4      With strong charger, balanced filling and floating filling 3-sectional series PWM adjust charing ways

5

      Automatic detection and tracking outside and battery temperature, built-in temperature compesation function

6

      Overakk electronic protection function,include overcharge put, overload,short-circuit,answer the reverse,etc

7

      Has the TVS lighting protection, no jump line design, can enhance the system relibiluty and durability

8

      Parameter Setting with power lsot save function,all importand date are keep in the chip

9

      Can work in cold ,high temperature,humid environment



SC-02 LCD display 30A solar controller (12V/24V auto detect)SC-02 LCD display 30A solar controller (12V/24V auto detect)SC-02 LCD display 30A solar controller (12V/24V auto detect)SC-02 LCD display 30A solar controller (12V/24V auto detect)
