Specifications
1. Hose Pump Applications2.Self-priming
3.Reversible
4.Easy maintenance,low cost,short down time
5.14 yesrs experience
| Pump Model | Output (L/h) | Pressure (MPa) | Hose ID (mm) | Rev. (r/min) | Max. ParticleDia.(mm) | Max. Suct.Left (m) | Motor Power (kW) |
| SH10 | 60 | 0.6 | 10 | 45 | 2 | 2 | 0.37 |
| SH10B | 100 | 0.6 | 10 | 80 | 2 | 2 | 0.37 |
| SH15 | 210 | 0.6 | 15 | 45 | 2 | 2 | 0.55 |
| SH15B | 300 | 0.6 | 15 | 75 | 2 | 2 | 0.55 |
| SH25 | 800 | 1.5 | 25 | 50 | 3 | 3 | 1.1 |
| SH25B | 1300 | 1.5 | 25 | 80 | 3 | 3 | 1.5 |
| SH32 | 1300 | 1.5 | 32 | 50 | 3 | 4 | 2.2 |
| SH32B | 1800 | 1.5 | 32 | 75 | 3 | 4 | 2.2 |
| SH38 | 2000 | 1.5 | 38 | 40 | 5 | 4 | 2.2 |
| SH38B | 2700 | 1.5 | 38 | 55 | 5 | 4 | 3 |
| SH38C | 3500 | 1.5 | 38 | 70 | 5 | 4 | 4 |
| SH50-558 | 4200 | 1.5 | 51 | 35 | 6 | 5 | 4 |
| SH50-558B | 5400 | 1.5 | 51 | 45 | 6 | 5 | 5.5 |
| SH50-680 | 6300 | 1.5 | 51 | 35 | 6 | 5 | 7.5 |
| SH50-680B | 8000 | 1.5 | 51 | 45 | 6 | 5 | 7.5 |
| SH65-680 | 9200 | 1.2 | 64 | 40 | 8 | 5 | 7.5 |
| SH65-680B | 12000 | 1.5 | 64 | 45 | 8 | 5 | 11 |
| SH65-770 | 13500 | 1.2 | 64 | 45 | 8 | 5 | 11 |
| SH65-770B | 16500 | 1 | 64 | 55 | 8 | 5 | 11 |
| SH76-770 | 18000 | 1 | 76 | 45 | 10 | 5 | 11 |
| SH76-770B | 22000 | 1 | 76 | 55 | 10 | 5 | 15 |
| SH76-915 | 24000 | 1 | 76 | 50 | 10 | 5 | 15 |
| SH76-915B | 28000 | 1 | 76 | 40 | 10 | 5 | 18 |
| SH100 | 33500 | 1 | 102 | 35 | 15 | 5 | 18 |
| SH100B | 42000 | 0.75 | 102 | 45 | 15 | 5 | 18 |
| • It can be produced according to the especcial requirement of client. | |||||||
| • The pump's output is determined with water. | |||||||
SINCOLA hose pumps SH10, SH15, SH25, SH32, SH38, SH50, SH65,
SH76, and SH100. For more detailed information, please see the specification.
·Reversibility
·Sealessness and valveless
·Abrasion resistance
·Self priming with high suction
· Hose Pumps is the only consumption part
Application Field
Phosphate fertilizer and compound fertilizer:It is used in metering fluid conveying at lab; spray granulation, concentrated slurry or depositing sludge conveying.
Mining and mill run:the transport of filling materials in gold mining and the pulp in gold melting; concentrated slurry, underpass draining, absorbents, mortar and grout, etc.
Gold mining industry:gold pulp and tailings.
Chemical industry:acid, alkali, phosphate slurry and titanium dioxide, etc. inorganic salt materials; crystal liquid, suspension liquid, latex, resin, ooze mud and various kinds of acid,alkali slurry.
Sewage treatment: the transport of silt slurry, lime mortar, etc.
Petroleum industry: the transport of drilling slurry and crude oil.
Ceramic industry:the transport of embryo pulp, clay glaze and ceramic glaze.
Papermaking industry:the transport of paper pulp and sulfur pulp.
Cosmetics:toothpaste, emulsion, hair conditioner, face cream, face oil, etc.
Building industry: sewage and gulf drainage, cement slurry, concrete slurry, ceiling coatings, etc.
Electroplating and electrolysis industry:electroplating solution, electrolyte solution, anode slime, precipitate, etc.
Food industry:the transport of oil materials and drink.
Medical industry:the transport of various kinds of medicine feeding liquids; the transport of radioactive waste liquid, electrolytic residues, metal slag, paint, coating, printing and dyeing auxiliaries, adhesives, glue, latexes, fireproof fiber slurry and other liquids of high sealing requirement,high viscosity and more particle content.
Packaging & Delivery
Wooden case packing or according to customers’requirement
Within 7 working days after we received advanced payment
Zhengzhou Sincola Machinery Co.,Ltd is a stated- designated manufacturer and exporter of road and building construction machineries. We are the one of the big manufacturer and supplierin China .
Our products are Shotcrete machinery and Concrete Pump,Plaster Machine, Mortar Pump,Spraying Machine, pumps and hose ,Grouting Pump,Automatic rendering machine. Also we are the manufactur,supplier and exporter of semi-automatic and full-automatic dry motar mixing plants.large and medium size of concrete mixing plants.
Our company engaged an international expert guidance, the study has been made a number of patents.Our technical experts from the United States, Germany, Italy and other multi-national team of experts.
Our products are well known to international market such as Russia, UzbekistanRussia,Uzbekistan,Cyprus,Algeria,Cameroon,Macedonia,Malaysia,Austrialia,Yemen,Oman etc.
Our products have widely been applying in construction, railway and super highway engineering, underground engineering, tunneling, mining operation,hydropower projects and slope stabilization.
