Home > Products > Dryer Machine > High quality cylinder dryer used in building materials/quartz sand
High quality cylinder dryer used in building materials/quartz sand
- 12 Set / Sets per Month
- Shanghai Qingdao Tianjin
- T/T L/C D/P D/A
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | SLL |
Model Number: | SLD | Voltage: | 380V or as you required | Power(W): | 5.5kw, 4-6KW |
Dimension(L*W*H): | Length 4m,Diameter 2m | Weight: | 5.3 t, 5.1t | Certification: | ISO9001:2008 |
Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas | Type: | Other, three return cylinder dryer |
Packaging Details
Nude packing or as per your requirement
Product Description
cylinder dryer used in building materials/quartz sand
8 '
30TPH Full automatic dry mortar mix plant | 25TPH Ladder type dry mortar production line | 10-15 TPH Tower full automatic dry mortar plant |
1-5TPH dry mortar plant | Single shaft coulter mixer | Double shaft dry mortar mixer |
Three Cylinder Dryer | Cement silo | Multi function screw mixer |
Parameter of three return cylinder dryer
Model | φ2.0×4 | φ2.5×5 | φ3.0×6 | φ3.6×8 |
Diameter (mm) | 2000 | 2500 | 3000 | 3600 |
Length (m) | 4 | 5 | 6 | 8 |
Volume (m³) | 12.6 | 24.5 | 42.4 | 81.4 |
Hoist Board Form | Screw propulsion | |||
Fill Rate | 10-20% | |||
Material | Heat resistant steel, stainless steel | |||
Operating Temperature | ≤700C° | |||
Evaporation Intensity (Kg/m.h)
| 20-80 | |||
Heating Type | Downstream, direct heating | |||
Heat Source | Coal, oil, electricity, gas, bio-fuel | |||
Rotation Speed (r/min) | 4-10 | |||
Driving Power (kw) | 5.5 | 11 | 15 | 22 |
Corollary Equipment | Conveying equipment, cowper stove, cyclone separator, draught fan, etc. |
Product Description of three return cylinder dryer
Zhengzhou sincola machinery co.,ltd. Three cylinder dryer Sand Drying Equipment is composed of three concentric cylinders of different diameters in accordance with mathematical relationship and structure form, embedded in each hpase.
Three cylinder dryer Sand Drying Equipment used for drying the fly ash,sand,mineral slag has improved original single drum dryer internal structure,added pre-drying before putting in the wet material and extended the material drying time in the machine ,plused sealed,moisturize, and the reasonable supporting measures.
Description of cylinder dryer used in building materials/quartz sand
The industrial three cylinder dryer is made up of three different diameter homocentric cylinder according to the certain mathematical relationship and cylinder structure then combinated by embedded with each another.Because of the three-cylinder dryer special structure, the length of the cylinder body is the single cylinder dryer one third.Base area than the single cylinder dryer save 65%, the basic investment corresponding reduced. This dryer adopts roller and belt friction transmission, has a low power transmission and reduces the noise of equipment. Sealing system uses a micro touch technology, has a better sealing effect, reduces the dust pollution. The three-cylinder dryer can adapt to coal, oil, gas and other various fuels, can dry lump, particle shape,and powder and so on many kinds of materials, accord with a policy to create an environment friendly, resource conservation-oriented society, and is an environmental protection energy-saving products which is the replacement of traditional drying equipment.
Pictures of three return cylinder dryer
Features of three return cylinder dryer
1.Three cylinder dryer for drying sand with telescope-feed structure can dry the material quickly.
2.Simple design and self-insulation can improve the heat efficiency to exceed 80%.
3.Structure is delicate, and stable is operation.
4.Good drying performance makes coal consumption
5.Reduce land area for 50% compared to single drum rotary dryer, so construction investment is saved 50%power and consumption saved 60%
Specifications of three return cylinder dryer
(1)Fly cutters, blades made of high strength wear resistant coating alloy material, which has long
service life.
(2)Fluidized bed combustion boiler has the high quality of combustion efficiency, supplying of heat
stably, low requirement of coal.
(3)Three cylinder dryers apply the latest European energy-saving technology - mosaic structure,
the inner barrel, middle barrel and outer barrel form a self heat insulation structure, reducing wind
tunnel thermal efficiency loss, increasing the heat exchange area and volumetric evaporation intensity,
which has outstanding energy-saving effect.
(4)The whole drying process is high automation, few operators are needed.
FAQ
1.How is the quality of your products?
Our products are manufactured strictly according to national and international standard,and we take a test on every grinder before delivered out. If you want see our quality certifications and all kinds of testing report, please just ask us for it.
2.Guarantee
If products’ quality don’t accord to description as we give or the promise before you place order,we promise 100% refund.
3.How about price?
Yes, we can be able to give you lowest price below market one, and we have a policy that “ for saving time and absolutely honest business attitude, we quote as lowest as possible for any customer, and discount can be given according to quantity”, if you like bargain and factory price is not low enough as you think, just don’t waste your time.Please trust the quotation we would give you, it is professional one.
4.Why should we choose you?
Chose happens because of quality, then price, we can give you both. Additionally, we can also offer professional products inquiry, products knowledge train(for agents), smooth goods delivery, excellent customer solution proposals.Our service formula: good quality+good price+good service=customer’s trust.
Company Profile
Zhengzhou Sincola Machinery Co., Ltd. is a high-technology, modern enterprise professionally engaged in the R&D and manufacturing of full automatic dry mortar plant and semi automatic dry mortar production line 1-5tph dry mortar plant and shotcrete machine plaster machine and mortar pump,wall rendering machine,concrete pump etc.
