Specifications
Sale Cheap Corn Drying MachineCapacity: 0.5 - 40 Ton per hour.
Dryer Drums
High Quality
High-efficiency
Long Term Supply Dryer Machine for drying wet sand.
" Dryer Drums "
Dryer, Capacity: 0.5-40 ton per hour !!!
Sand Dryer Machine for Drying Coal, Sand!
Dryer Drums
Dryer Machine for Drying Coal , Wet Sand Dryer.
Rotary Dryer Rotary Dryer mainly consists of rotary body, raw material feeding plate, driving and supporting device, etc. Rotary Dryer is mainly used for cement, chemical, metallurgical, building materials industries
Now we have some cheap and high quality Small Dryer, Coal Dryer ,Sand Dryer machine For Sale.
The following is the technical Parameters of Dryer Drums
|
Model (mm) |
Diameter (mm) |
Length (mm) |
Gradient |
Rotate speed (r/m) |
Weight |
Power |
Volume (M3) |
φ600×8 |
φ600 |
8000 |
3-5 |
8 |
5.1 |
4-6 |
2.26 |
φ800×10 |
φ800 |
10000 |
3-5 |
7.2 |
6.9 |
4-6 |
5.02 |
φ1000×10 |
φ1000 |
10000 |
3-5 |
6.73 |
7.5 |
5.5-6 |
7.85 |
φ1200×12 |
φ1200 |
12000 |
3-5 |
5.8 |
13.1 |
6-11 |
13.31 |
φ1500×12 |
φ1500 |
12000 |
3-5 |
4.8 |
22.3 |
6-15 |
21.2 |
φ2200×14 |
φ2200 |
14000 |
3-5 |
3.2 |
52.8 |
30 |
53.22 |
φ2400×18 |
φ2400 |
18000 |
3-5 |
3 |
73.3 |
37 |
81.43 |
φ2800×24 |
φ2800 |
24000 |
3-5 |
2.59 |
97 |
75 |
147.8 |
Rotary Dryer Drums
Application of Dryer Machine for Drying Coal , Drum Dryer , Sand Dryer Machine
For dry mix mortar production line drying sand
Rotary Dryer mainly consists of rotary body, raw material feeding plate, driving and supporting device, etc. Rotary Dryer is mainly used for cement, chemical, metallurgical, building materials industries. Its advantages are as follows: high dry capacity, smooth rotation, low energy consumption, easy operation, high output and so on.
Sand Dryer For Sale !!!!!!
Features of Rotary Drum Dryer
Sand dryer machine is handling by bringing it into direct contact with a heated gas. The sand dryer consists of revolved body, raise material board, transmission device, support device and seal ring etc ,The dryer slopes slightly so that the discharge end is lower than the material feed end in order to convey the material through the dryer under .
Advantages of Dry Machine - Dryer Machine for Drying Coal :
- Save floor space of the rotary dryer machine; Lower cost than normal dryer;
- The temperature of the final product is low, the life of dust collector is long;
- The material of this dryer is alloy steel, more wear-resistant and longer life than normal dryer;
- It is the best machine on drying silica sand and other sand shape material;
- Because the temperature of the final product is low, so the final product can be packed directly and continuously;
- The fuel can be coal, oil, gas and so on; It can be adjusted the humidity very easy.
Working Principle of Drying Machine
Material to be dried enters the dryer, and as the dryer rotates machine, the material is lifted up by a series of internal fins lining the inner wall of the dryer. When the material gets high enough to roll back off the fins, it falls back down to the bottom of the dryer, passing through the hot gas stream as it falls. This gas stream can either be moving toward the discharge end from the feed end (known as co-current flow), or toward the feed end from the discharge end (known as counter-current flow). The gas stream can be made up of a mixture of air and combustion gases from a burner, in which case the dryer is called a direct
heated dryer. Alternatively, the gas stream may consist of air or another (sometimes inert) gas that is preheated. When the gas stream is preheated by some means where burner combustion gases do not enter the dryer, the dryer known as an indirect-heated type. Often, indirect heated dryers are used when product contamination is a concern.
Delivery of Sand Dryer :
