Specifications
Sale Cheap Drum DryerSand Dryer For Sale
Cheap Dryer Machine for Drying Coal
High Quality
High-efficiency
Long Term Supply Dryer Machine for drying wet sand.
Sand Dryer For Sale !!!
Dryer Machine for Drying Coal !
Dryer Machine for Drying Coal , Wet Sand Dryer ---- Drum Dryer
Three cylinder dryer, Drum Dryer is composed of three concentric cylinders of different diameters in accordance with certain mathematical relationship and structural form, embedded in each phase. It can dry various of materials.
Now we have some cheap and high quality Coal Dryer ,Sand Dryer For Sale.
Model (mm) |
Inclination (%) |
Rotate speed (r/min) |
Air inlet temperature(° C) |
Power (kw) |
Production capacity(t/h) |
Weight (t) |
Φ 600x6000 |
3-5 |
3-8 |
≤ 700 |
3 |
0.5-1.5 |
2.9 |
Φ 800x8000 |
3-5 |
3-8 |
≤ 700 |
4 |
0.8-2.0 |
3.5 |
Φ 800x10000 |
3-5 |
3-8 |
≤ 700 |
4 |
0.8-2.5 |
4.5 |
Φ 1000x10000 |
3-5 |
3-8 |
≤ 700 |
5.5 |
1.0-3.5 |
5.6 |
Φ 1200x10000 |
3-5 |
3-8 |
≤ 700 |
7.5 |
1.8-5 |
14.5 |
Φ 1200x12000 |
3-5 |
3-8 |
≤ 700 |
11 |
2-6 |
14.8 |
Φ 1500x12000 |
3-5 |
2-6 |
≤ 800 |
15 |
3.5-9 |
17.8 |
Φ 1800x12000 |
3-5 |
2-6 |
≤ 800 |
18 |
5-12 |
25 |
Φ 2200x12000 |
3-5 |
1.5-6 |
≤ 800 |
18.5 |
6-15 |
33 |
Φ 2200x18000 |
3-5 |
1.5-6 |
≤ 800 |
22 |
10-18 |
53.8 |
Φ 2200x20000 |
3-5 |
1.5-6 |
≤ 800 |
30 |
12-20 |
56 |
Φ 2400x20000 |
3-5 |
1.5-5 |
≤ 800 |
37 |
18-30 |
60 |
Φ 3000x20000 |
3-5 |
1.5-5 |
≤ 800 |
55 |
25-35 |
78 |
Φ 3000x25000 |
3-5 |
1.5-5 |
≤ 800 |
75 |
32-40 |
104.9 |
The above is the technical parameters of Sand Dryer, Coal Dryer - Drum Dryer .
Application of Dryer Machine for Drying Coal , Drum Dryer , Sand Dryer Machine
Rotary drier is used to dry slag, clay, limestone, Three cylinder dryer is mainly used for cement, chemical, metallurgical, building materials industries.
Indirect heat transfer drier Three cylinder dryer is used for drying materials with humidity or granularity in the industries of mineral dressing, building material, metallurgy and chemical. Rotating dryer can be used for drying many kinds of materials and with convenient and reliable operation; therefore, it has been widely used.
Sand Dryer For Sale !!!!!!
Features of Sand Dryer:
- With high technical content, cylinder self insulation, thermal efficiency is as high as 80% (single cylinder dryer is only 35 percent), thermal efficiency than single cylinder drying saves coal 68 percent, yields 100%.
- Compared to single cylinder dryer the machine length shortens 60%, in favour of process arrangement. Reduces workshop covered area, saves the project investment by around 40%.
- Covers an area of about 20m2. Heat-resisting wear-resisting alloy steel plate, four times than ordinary steel wear- resisting. Long service life and easy maintenance.
- High thermal efficiency, outside shell temperature below 60 °C (single cylinder dryer outside shell temperature as high as 150°C), output of low temperature, discharging temperature below 60 °C.
- Output of low temperature, be helpful for dust removal equipment to use a long time, can be directly supporting air tankpulse bag filter.
- Construction investment reduces 50% or so, power consumption reduces 60%.
- Don't need sizes of gear-driving,and adopts roller rotation.
- Hot air stove can supporting fluidezed bed, spray stove, hands burned furnace, also used in fuel and gas type, can bake the below 20 mm pieces of materials, aggregates, powder material.
Advantages of Dry Machine - Dryer Machine for Drying Coal :
Save floor space of the three cylinder dryer machine;
Lower cost than normal dryer;
The temperature of the final product is low, the life of dust collector is long;
The material of this dryer is alloy steel, more wear-resistant and longer life than normal dryer;
It is the best machine on drying silica sand and other sand shape material;
Because the temperature of the final product is low, so the final product can be packed directly and continuously;
The fuel can be coal, oil, gas and so on;
It can be adjusted the humidity very easy.
Delivery of Sand Dryer :
