API610 Axially Split Pump Horizontal Water Treatment Centrifugal Pump

US$ 4,000 - 8,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

Model Number:

DKBB

Shijiazhuang Damei Kingmech Pump Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

DALIAN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name DK

Model Number DKBB

Theory Centrifugal Pump

Structure Single-stage Pump

Usage Other, Chemical liquid

Power Hydraulic

Standard or Nonstandard Nonstandard

Fuel Other, electric

Pressure High Pressure

Application Other, chemical industry Petro-chemical

Product Description

Application

Type MSH high pressure boiler feed pumps are used for feeding high pressure boiler of pumping high pressure clean water.
The temperature of pumped media is not more than 210°C.
Range of capacity: 100 to 580m³/h.
Range of total head: 740 to 2150m.

Construction

The pumps are sectional casing, multi-stage centrifugal pumps. The suction casing, stage casing and discharge casing are rigidly held together by the bolts. The joints between these casing are primarily sealed by means of metal-metal contact. Simultancously ,o-rings are used as auxiliary seals.
The forged pieces are used for the suction ,stage and discharge casings of type MSHB pressure boiler feed pumps.

Shaft sealing

The shafts of these pumps are sealed by soft-packing and cooling water . In the region of shaft sealing ,the pump shaft is protected by renewable sleeve.

Bearings and axial balancing device

The rotating assembly is supported by sliding bearings on both ends of the pump shaft . Bearings of pump are forced-lubricated. The oil system is equipped for type DG pump. The axial thrust of rotor osis balanced by balance disc.
And the thrust bearing is laso provided which is rsed to bear residral axial force caused by the change of working conditions.

Drive

The pump is directly driven by the motor through the coupling. The gear, membrane coupling and hydraulic coupling can be
used according to client’s requirements. The pump can be driven by turbine of motor.
The rotating direction of pumps are clockwise when viewed fron the driving end.

Material

Suction casing ,discharge casing, diffuser, and impeller: carbon steel of chrome steel.
Shaft, wear ring and diffuser bush: chromic alum steel of chrome steel.
