2016 xcmg tower crane
Track traveling type tower crane
Zhengzhou Sincola Machinery Co.,Ltd. Track type tower crane is one of new products of our company. It's a crane whose traveling mechanism is mounted on guide track basing on the cross beam of stationary tower crane QTZ160, QTZ125, QTZ80 and QTZ63.
Model | QTZ80(5512) | QTZ63(5013) | QTZ63C(5211) |
Amplitude (M) | 55 | 50 | 52 |
Independent Height (M) | 46 | 41 | 40 |
Max. Height (M) | 151 | 141 | 140 |
Max. Lifting Capacity (T) | 8 | 6 | 6 |
Assistant Support Frame | 5 | 4 | 5 |
Main Material | 135×135×12 (square steel tube) | 135×135×10 | ∠160*16 |
Standard Mast Section Dimension | 1.835×1.835×2.5 | 1.835×1.835×2.5 | 1.615×1.615×2.5 |
Lifting Speed (a=2) (m/min) | 100/50 | 80/40/8.5 | 80/40/8.5 |
Slewing Speed (r/min) | 0.65 | 0.64 | 0.64 |
Trolley Travel Speed ( m/min) | 60/30/10 | 42/21 | 42/21 |
Max. Lifting Moment (KNm) | 800 | 630 | 630 |
Working Temperature(°C) | -20~+40 | -20~+40 | -20~+40 |
Undercarriage Form | Type A. Cross-shaped beam with slanting strut and ballast Type B. C, ro, ss, -sh, aped beam with slanting strut but no ballast | Type A. Cross-shaped beam with slanting strut and ballast Type B. Cross-shaped beam with slanting strut but no ballast | Type A. #-shaped Beam without ballast Type B. Cross-shaped beam with slanting strut and ballast |
Model | QTZ50(4810) | QTZ40(4708) | QTZ40(4708) |
Amplitude (M) | 48 | 47 | 45 |
Independent Height (M) | 35 | 32.5 | 32.5 |
Max. Height (M) | 140 | 100 | 100 |
Max. Lifting Capacity (T) | 6 | 4 | 4 |
Assistant Support Frame | 4 | 4 | 4 |
Main Material | 135×135×10 | 160×160×12 | 160×160×12 |
Standard Mast Section Dimension | 1.835×1.835×2.5 | 1.5×1.5×2.5 | 1.5×1.5×2.5 |
Lifting Speed (a=2)(m/min) | 76/36/8 | 69.4/34.7 | 76/38/10 |
Slewing Speed (r/min) | 0.64 | 0.62 | 0.77 |
Trolley Travel Speed (m/min) | 42/21 | 38/19 | 21.6/43.2 |
Max. Lifting Moment (KNm) | 500 | 400 | 400 |
Working Temperature (°C) | -20~+40 | -20~+40 | -20~+40 |
Undercarriage Form | Type A. Cross-shaped beam with slanting strut and ballast Type B. Cross-shaped beam with slanting strut but no ballast
| Type A. Cross-shaped beam with slanting strut and ballast Type B. Cross-shaped beam with slanting strut but no ballast Type C.#-shaped beam without ballast | Type A. Cross-shaped beam with slanting strut and ballast Type B. Cross-shaped beam with slanting strut but no ballast Type C.#-shaped beam without ballast |
