2016 construction hoist tower crane
Track traveling type tower crane
Zhengzhou Sincola Machinery Co.,Ltd. Track type tower crane is one of new products of our company. It's a crane whose traveling mechanism is mounted on guide track basing on the cross beam of stationary tower crane QTZ160, QTZ125, QTZ80 and QTZ63.
Model |
QTZ80(5512) |
QTZ63(5013) |
QTZ63C(5211) |
Amplitude (M) |
55 |
50 |
52 |
Independent Height (M) |
46 |
41 |
40 |
Max. Height (M) |
151 |
141 |
140 |
Max. Lifting Capacity (T) |
8 |
6 |
6 |
Assistant Support Frame |
5 |
4 |
5 |
Main Material |
135×135×12 (square steel tube) |
135×135×10 |
∠160*16 |
Standard Mast Section Dimension |
1.835×1.835×2.5 |
1.835×1.835×2.5 |
1.615×1.615×2.5 |
Lifting Speed (a=2) (m/min) |
100/50 |
80/40/8.5 |
80/40/8.5 |
Slewing Speed (r/min) |
0.65 |
0.64 |
0.64 |
Trolley Travel Speed ( m/min) |
60/30/10 |
42/21 |
42/21 |
Max. Lifting Moment (KNm) |
800 |
630 |
630 |
Working Temperature(°C) |
-20~+40 |
-20~+40 |
-20~+40 |
Undercarriage Form |
Type A. Cross-shaped beam with slanting strut and ballast Type B. C, ro, ss, -sh, aped beam with slanting strut but no ballast |
Type A. Cross-shaped beam with slanting strut and ballast Type B. Cross-shaped beam with slanting strut but no ballast |
Type A. #-shaped Beam without ballast Type B. Cross-shaped beam with slanting strut and ballast |
Model |
QTZ50(4810) |
QTZ40(4708) |
QTZ40(4708) |
Amplitude (M) |
48 |
47 |
45 |
Independent Height (M) |
35 |
32.5 |
32.5 |
Max. Height (M) |
140 |
100 |
100 |
Max. Lifting Capacity (T) |
6 |
4 |
4 |
Assistant Support Frame |
4 |
4 |
4 |
Main Material |
135×135×10 |
160×160×12 |
160×160×12 |
Standard Mast Section Dimension |
1.835×1.835×2.5 |
1.5×1.5×2.5 |
1.5×1.5×2.5 |
Lifting Speed (a=2)(m/min) |
76/36/8 |
69.4/34.7 |
76/38/10 |
Slewing Speed (r/min) |
0.64 |
0.62 |
0.77 |
Trolley Travel Speed (m/min) |
42/21 |
38/19 |
21.6/43.2 |
Max. Lifting Moment (KNm) |
500 |
400 |
400 |
Working Temperature (°C) |
-20~+40 |
-20~+40 |
-20~+40 |
Undercarriage Form |
Type A. Cross-shaped beam with slanting strut and ballast Type B. Cross-shaped beam with slanting strut but no ballast
|
Type A. Cross-shaped beam with slanting strut and ballast Type B. Cross-shaped beam with slanting strut but no ballast Type C.#-shaped beam without ballast |
Type A. Cross-shaped beam with slanting strut and ballast Type B. Cross-shaped beam with slanting strut but no ballast Type C.#-shaped beam without ballast |
