Specifications
HD pump is single casing radially split multistage between bearing pump designed according to API610.
HD pump is single casing radially split multistage between bearing pump designed according to API610.
Feature
THE pump are sectional casing ,multi-stage centrifugal pumps.
The suction casing and discharge caseing are rigidly held together by the bolts.
The suction can be either horizontal or up direction. The joints bestween these casing are promarilt sealed
by means of metal -metal contact . Simultaneously, O-ring are usedas auxiliary seals.
The forged pieces can be used for the sucion, stage and discharge casing of type HD (HDF) high pressure mulitistage centrifugal pumps
Size: 4-10 inches
Capacity: 100-580 m3/h
Head: 740-2150m
Temperature: 0-210 °C
Material: Cast steel, SS304, SS316, SS316Ti, SS316L, CD4MCU
