24kw Deutz Power Generation System Air Cooling Generator
- Shanghai port
- T/T
You May Like
-
30kva Diesel Generator Power Equipment Air Cooled Genset
-
Silent Power Genset 33kva Deutz Air Cooling Diesel Generator
-
Low Noise Silent Cabin Water Proof Deutz Diesel Genset Price
-
20kva Generator Air Cooled Deutz Diesel Genset
-
Trailer Type Portable Power Supplier Deutz Genset Price
-
Small Diesel Power Generation Deutz Air Cooled Generator
Product Details
| Place of Origin | Jiangsu, China | Brand Name | air cooling generator | |
| Model Number | ZCDL-D24 | Output Type | AC Three Phase | |
| Speed | 1500RPM | Frequency | 50Hz | |
| Rated Power | 24kw air cooling generator | Rated Voltage | 400/230V | |
| Rated Current | 43A |
Product Description
24kw deutz power generation system air cooling generator
| MODEL | ZCDL-D24 | |||||||
| Standby Power(50Hz) | 26KW/33KVA | |||||||
| Prime Power(50Hz) | 24KW/30KVA | |||||||
| ENGINE DATA | ||||||||
| Brand and Model: | Deutz F4L912 | |||||||
| Air Intake System: | Natural | |||||||
| Cool System: | Air-cooled | |||||||
| Fuel System: | Direct Injection | |||||||
| Cylinder: | 4 | |||||||
| Displacement: | 3.77L | |||||||
| Bore and Stroke: | 100×120(mm) | |||||||
| Rated RPM: | 1500rpm | |||||||
| Engine Max. Power: | 35kw | |||||||
| Compression Ratio: | 17:1 | |||||||
| Lub.-Oil Capacity: | 12L | |||||||
| Air Intake Capacity: | 2.83m3/min | |||||||
| Exhaust Capacity: | 2.91m3/min | |||||||
| Exhaust Temperature: | 500℃ | |||||||
| Lub.-Oil Consumption: | 1% of Diesel Consumption | |||||||
| 100% Load Consumption: | 228 g/kw.h | |||||||
| 75% Load Consumption: | 238 g/kw.h | |||||||
| 50% Load Consumption: | 248 g/kw.h | |||||||
| Start Type: | 24V Direct Current Start, Including alternator & battery | |||||||
| Filter System: | Dry type air filter, fuel filter, oil filter | |||||||
| ALTERNATOR DATA | ||||||||
| Brand and Model: | Stamford PI144G | |||||||
| Rated Power: | 30kva | |||||||
| Connecting Type: | 3 Phase and 4 Wires, “Y” type connecting | |||||||
| Power Factor: | 0.8 | |||||||
| Protection Grade: | IP23 | |||||||
| Altitude: | ≤1000m | |||||||
| Exciter Type: | Brushless, self-exciting, with AVR | |||||||
| Insulation Class, Temperature Rise: | H/H | |||||||
| Telephone Influence Factor (TIF): | <50 | |||||||
| THF: | <2% | |||||||
| GENERATING SET DATA | ||||||||
| Voltage Regulation, Stead State: | ≤±1% | |||||||
| Sudden VoltS Warp(100%): | ≤+20% | |||||||
| Sudden Voltage Warp(Sudden Increase): | ≤-15% | |||||||
| Voltage Stable Time: | ≤4S | |||||||
| Frequency Regulation, Stead State: | ≤5% Adjustable | |||||||
| Frequency Waving: | ≤±0.5% | |||||||
| Sudden Frequency Warp(100%): | ≤-7% ~ +10% | |||||||
| Frequency Recovery Time: | ≤3S | |||||||
| Attached Accessories: | Starting batteries and connective wires, ripple flex exhaust pipe, exhaust siphon, muffler, damper, MCCB breaker | |||||||
| Manufacturing Standards: | CE, ISO9001, ISO14001 | |||||||
| Open Type Overall Size: | 1600(mm)*800(mm)*1230(mm) | |||||||
| Open Type Weight: | 650kg | |||||||
| Control Panel: | UK Deepsea DSE702 Manual Control Panel | |||||||
Open Genset:
Silent Genset:
Trailer Generator:
air cooling generator Packaging: nude or plywood package
air cooling generator Shipping: 20 days after deposit
(1) air cooling generator Warranty time: 1 year or 1000 running hours, which occurs the first
Yangzhou Zhengchi Power Equipment Co, Ltd, locates in Yangzhou City, Jiangsu Province, which is the manufacturing centrality of air cooling generator industrial zone in Southeast China, Zhengchi Power owns 3 subsidiary factories, one is to produce brushless alternator, second is to produce silent canopy and trailer, third is to assemble diesel generator set, registered capital with 61000000.00 RMB.
Zhengchi Power is specialized in manufacturing air cooling generator and supplying various power products, like engine parts, controllers, ATS etc. Zhengchi Power manufactures OEM generator powered by Cummins, Deutz, Volvo, MTU, Doosan engines and Stamford, Leroy Somer, Mecc Alte alternators.
(1) Your company is factory or Trade Company?
Answer: We are professional air cooling generator manufacturing factory.
(2) Your diesel generator power range?
Answer: Now we mainly produce 7KW to 2400KW air cooling generator.
(3) Which brand Electrical Generator you produce?
Answer: Now we produce USA brand diesel generator, Sweden Volvo Generator, Korea Doosan diesel generator, German Deutz air cooling generator, and China local brands' generator.
(4) Where is your main market?
Answer: We mainly export air cooling generator to Africa, Middle East, Asia, and South Korea...
